ASSMANN WSW IC Socket Adapter Straight Through Hole Mount 2.54 mm Pitch DIP to DIP AR 24-ST/T

Name: ASSMANN WSW IC Socket Adapter Straight Through Hole Mount 2.54 mm Pitch DIP to DIP AR 24-ST/T
Brand: ASSMANN WSW
SKU: 208598
Price: 20.22 USD
Availability: InStock



Category IC Socket Adapter Brand ASSMANN WSW Condition New

Specifications

Country of Origin	China
Voltage	100V ac
Brand	ASSMANN WSW
Orientation	Straight
Current	3A
Model	AR 24-ST/T
Mount Type	Through Hole
Housing Material	Polybutylene Terephthalate
Contact Material	Brass
Pitch	2.54mm
Contact Plating	Gold over Nickel
Connection Gender A	Male
Number of Contacts A	24
Connection A	DIP

Key Features

Provides a straight through hole mount configuration for easy PCB integration.
Features 24 male contacts on both connection sides for full signal transmission.
Constructed with brass contact material offering durability.
Contacts plated with gold over nickel to ensure excellent conductivity and corrosion resistance.
Operates at a current rating of 3A and a voltage rating of 100V AC for safe and efficient usage.
Housing made of polybutylene terephthalate for robustness and insulation.
Compact and standardized 2.54 mm pitch supports common DIP packages.
Manufactured in China maintaining consistent quality standards.

Product Description

The ASSMANN WSW AR 24-ST/T is a high-quality IC socket adapter designed to facilitate straight through hole mounting with a 2.54 mm pitch suitable for DIP to DIP connections. This adapter is specifically engineered for efficient and dependable signal transmission between compatible IC components and PCBs.

Equipped with 24 male contacts on both connection sides made from brass, the adapter ensures mechanical strength and optimal electrical performance. The gold over nickel contact plating further enhances conductivity while protecting against corrosion and wear during repeated insertions and removals.

Rated for a current of 3A and voltage of 100V AC, it efficiently supports various industrial and electronic applications requiring compact and reliable socket connectivity. The housing material, polybutylene terephthalate, provides excellent electrical insulation and mechanical durability, allowing the adapter to withstand demanding operational environments.

This adapter’s straight through hole mount design simplifies PCB assembly processes, making it ideal for electronics manufacturing, prototyping, and repair tasks. Its standardized 2.54 mm pitch is widely compatible with standard DIP components, ensuring broad utility.

Provides a straight through hole mounting mechanism for secure PCB attachment. 24 male contacts on both connection ends for full signal path support. Brass contact construction for mechanical and electrical reliability. Gold over nickel plating enhances conductivity and corrosion resistance.

3A current rating and 100V AC voltage rating ensure safe operational limits. Polybutylene terephthalate housing resists wear and insulates effectively. Standard 2.54 mm pitch supports most DIP format ICs. Manufactured in China to consistent quality specifications.

Applications include electronic component interconnection, PCB prototyping, and industrial automation systems. Explore more IC Socket Adapters and related connectors on EnvMart for your diverse industrial, electronics, laboratory, and manufacturing needs.
