ASSMANN WSW AWHW Series Right Angle Through Hole PCB Header, 20 Contacts, 2.54 mm Pitch, 2 Row, Shrouded AWHW 20A-0202-T
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | ASSMANN WSW |
| Orientation | Right Angle |
| Current | 3A |
| Model | AWHW 20A-0202-T |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | AWHW |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold, Nickel |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Features a dual-row configuration for secure connections.
- Contact pitch of 2.54 mm ensures compatibility with standard PCBs.
- Designed with brass contacts plated in gold and nickel for durability.
- Housing made from robust Polybutylene Terephthalate for heat resistance.
- Supports up to 3 Amperes current carrying capacity.
- Rated for 250 Volts operating voltage to suit various electronics applications.
- Male contacts with shrouded mounting enhance protection and reliability.
- Termination type is solder, suitable for through-hole PCB mounting.
Product Description
ASSMANN WSW AWHW 20A-0202-T is a right angle through hole PCB header designed to provide reliable wire-to-board connections in electronic assemblies. This PCB header features 20 male contacts arranged in two rows with a 2.54 mm pitch, conforming to common PCB standards.
The contacts are made of brass and plated with gold and nickel to ensure excellent conductivity and resistance to corrosion, enhancing the product's longevity and performance. The housing is constructed from durable Polybutylene Terephthalate (PBT), which offers high thermal stability and mechanical strength.
Rated to carry up to 3A current and operate at voltages up to 250V, this header is suitable for varying industrial, electronic, and commercial applications. Its solder termination type and through-hole mount ensure secure solder joint formation on printed circuit boards for stable electrical connections.
The header’s shrouded design protects the contacts and prevents accidental short circuits. It is designed to operate within a wide temperature range from -40°C to +105°C, making it suitable for use in harsh environmental conditions.
Compliance with RoHS regulations confirms the absence of hazardous substances, making it environmentally friendly. This product is ideal for manufacturing, electronics repair, and testing applications requiring secure, compact connector solutions.
Dual-row 20 contact PCB header with 2.54 mm pitch. Brass contacts plated with gold and nickel for reliable connections. Polybutylene Terephthalate housing for enhanced durability. 3A current and 250V voltage rating. Shrouded male contacts with solder termination.
Operating temperature range from -40°C to 105°C. Complies with RoHS for environmental safety. Explore more high-quality PCB Headers and connectors at EnvMart to support your industrial and commercial electronics projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports up to 3 Amperes current carrying capacity.
This model is rated for an operating voltage of 250 Volts.
The contact pitch is 2.54 mm, ensuring compatibility with standard PCBs.
The contacts are made of brass plated with gold and nickel, while the housing is constructed from Polybutylene Terephthalate (PBT).
It features a solder termination type suitable for through-hole PCB mounting.
It operates within a temperature range from -40°C to +105°C.
This unit has 20 male contacts arranged in a dual-row configuration.
Yes, it complies with RoHS regulations, confirming the absence of hazardous substances.
The header is designed in a right angle orientation for efficient space utilization.
It utilizes a wire-to-board connector system for reliable connections.
It is suitable for various industrial, electronic, and commercial applications requiring secure connections.
The country of origin for this product is India.
