ASSMANN WSW 9-Way IDC Connector Female for Cable 2 Row 250V AC 1A A-DFF 09LPIII/Z-UNC

Free Delivery in India | Lowest Global Shipping Charges

ASSMANN WSW 9-Way IDC Connector Female for Cable 2 Row 250V AC 1A A-DFF 09LPIII/Z-UNC

Name: ASSMANN WSW 9-Way IDC Connector Female for Cable 2 Row 250V AC 1A A-DFF 09LPIII/Z-UNC
Brand: ASSMANN WSW
SKU: 208269
Price: 1.86 USD
Availability: InStock



Category IDC Connector Brand ASSMANN WSW Condition New

Specifications

Country of Origin	China
Voltage	250V ac
Brand	ASSMANN WSW
Orientation	Straight
Current	1A
Model	A-DFF 09LPIII/Z-UNC
Mount Type	Cable
Housing Material	Polybutylene Terephthalate
Contact Material	Brass
Series	AD
Termination Type	IDC
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Tin, Nickel, Gold
Number of Contacts	9
Contact Gender	Female
Connector Gender	Female
Shrouded/Unshrouded	Shrouded

Key Features

Features 9 contacts arranged in 2 rows for efficient wiring.
Supports a current rating of 1 ampere for moderate electrical loads.
Standard 2.54 mm pitch ensures compatibility with common electronics.
Shrouded design enhances contact protection and durability.
Tin, nickel, and gold plating provide excellent corrosion resistance.
Constructed with brass contacts and polybutylene terephthalate housing for robust performance.
Operates safely within -55°C to 105°C temperature range.
Straight orientation allows easy cable mounting with IDC termination type.

Product Description

ASSMANN WSW A-DFF 09LPIII/Z-UNC 9-Way IDC Connector Female for Cable, 2 Row is a cable mount IDC connector designed to deliver reliable and efficient connectivity in electronic assemblies requiring up to 1 amp current and 250 volts AC.

This connector features 9 contacts organized in two rows with a 2.54 mm pitch, facilitating precise and consistent wiring for printed circuit boards and wire harnesses.

Its shrouded design offers improved protection of contacts, while the tin, nickel, and gold plating ensure excellent corrosion resistance and durable electrical performance. Manufactured with brass contacts and a polybutylene terephthalate housing, it provides robust mechanical stability and temperature endurance from -55°C to 105°C.

The straight orientation and IDC termination type allow for easy cable insertion and termination without soldering, enhancing installation efficiency in industrial, laboratory, manufacturing, and commercial electronic applications.

Designed under the AD series, this female connector is capable of supporting various electronics requiring secure and reliable interconnections at moderate current and voltage levels.

Features 9 contacts arranged in 2 rows for efficient wiring. Supports a current rating of 1 ampere for moderate electrical loads. Standard 2.54 mm pitch ensures compatibility with common electronics. Shrouded design enhances contact protection and durability.

Tin, nickel, and gold plating provide excellent corrosion resistance. Constructed with brass contacts and polybutylene terephthalate housing for robust performance. Operates safely within -55°C to 105°C temperature range.

Straight orientation allows easy cable mounting with IDC termination type. Rated for 250 volts AC, suitable for various PCB wiring applications. Manufactured in China under the AD series with female connector gender. This connector is commonly used in electronic component assemblies, industrial control systems, and communications devices requiring quick and reliable cable connections.

Explore more IDC Connectors and related products at EnvMart under Electronics & Electricals, Electronics Components.
