ASSMANN WSW 37-Way IDC Connector Male for Cable, 2 Row, 250V AC, 1A, Pitch 2.54mm, Gold Nickel Tin Plating A-DSF 37LPIII/Z

ASSMANN WSW A-DSF 37LPIII/Z is a high-quality 37-Way IDC Connector Male designed for cable mounting with a two-row configuration suitable for various demanding electronic and industrial applications. Rated for 250V AC and 1A current, this connector ensures stable electrical performance even in harsh environmental conditions.

The 2.54mm pitch and shrouded contact design provide secure and reliable mating with compatible connectors and PCBs. Gold, nickel, and tin plating on the brass contacts enhances conductivity while protecting against corrosion, ensuring long-term durability. The housing made from polybutylene terephthalate offers excellent mechanical resistance and insulation.

With a wide operating temperature range from -55°C to 105°C, this IDC connector is suitable for a broad spectrum of applications including industrial equipment, manufacturing automation, electronic component assembly, and power connectors in automation and control gear.

The cable mount type with IDC termination simplifies wiring processes and increases production efficiency by allowing quick insertion without special tools. Its male connector gender with a straight orientation facilitates versatile cable routing options.

The connector features 37 contacts arranged in 2 rows for efficient wiring. Contact pitch is standardized at 2.54mm ensuring compatibility with PCBs and cables. Gold, nickel, and tin plating on contacts improves conductivity and corrosion resistance.

The housing is made of durable polybutylene terephthalate for high mechanical strength. Designed for cable mount with IDC termination allowing quick and secure cable insertion. Operating temperature range from -55°C to 105°C enables usage in diverse environments.

Shrouded design protects contacts and prevents accidental shorts. Connector gender is male with straight orientation acceptable for many wiring layouts. Contact material of brass ensures reliable electrical performance and mechanical durability.

Ideal for industrial, electronic assembly, and manufacturing applications.

The ASSMANN WSW IDC connector line exemplifies industrial-grade quality and reproducibility. This product is manufactured in China and adheres to stringent quality controls to meet the demands of electronics and power connector markets.
