Molex Micro-Fit TPA Female Connector Housing 3 mm Pitch 10 Way 2 Row Straight 172952-1001

Molex 172952-1001 Micro-Fit TPA Female Connector Housing offers a reliable and compact connector solution for electronic applications requiring secure wire-to-wire connections. It features a 3 mm pitch with 10 contacts arranged in 2 rows in a straight orientation, made from high-quality nylon housing material providing durability and electrical insulation. This connector housing incorporates an integrated Terminal Position Assurance (TPA) system with a secondary lock mechanism designed to significantly reduce the risk of terminal back-outs and improve connection reliability.

The single row version's one-piece design simplifies assembly by eliminating additional secondary components, while the polarized housings prevent accidental mis-mating. Locking latches provide a robust and secure mating connection ensuring stability in demanding environments. The contacts are fully isolated within the housing to prevent arcing, enhancing safety and performance.

This Micro-Fit TPA 3.0 mm connector housing is compatible with Micro-Fit 3.0 female crimp terminals (stock number 43030) and RMF reduced mating force contacts (stock number 46235), allowing integration into existing systems without additional design costs.

Common application areas include consumer and home appliances, data and computing systems such as desktops, workstations, and power supplies, as well as telecommunications infrastructure including servers, routers, and switches. It is also well-suited for automotive and commercial vehicle harnesses in non-sealed internal devices.

Integrated TPA with secondary lock reduces terminal back-outs for reliable connection. One-piece housing design eliminates the need for secondary pieces in single row versions. Polarized housing prevents mis-mating and incorrect connections.

Durable nylon housing material provides mechanical and electrical integrity. Compatible with Micro-Fit 3.0 male crimp terminals and RMF variants. Ideal for use in electronics, telecommunications, automotive, and computing applications.

Compact 6.86 mm width and 15.85 mm length dimensions fit tight spaces.

This connector housing is manufactured in China and designed to meet high standards of connector reliability without specific certifications. Environmentally robust and designed for ease of assembly, it enables secure and efficient wiring solutions. Browse more Electronic Components and Connector Housing products at EnvMart for comprehensive wiring solutions.
