Molex C-Grid III Series Straight Through Hole Pin Header 22 Contacts 2.54 mm Pitch 1 Row Unshrouded 90120-0782
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 22 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Designed for board to board and wire to board connections.
- Features a breakaway design allowing size customization.
- Constructed with brass contacts plated in gold for reliable conductivity.
- Capable of carrying 3A current with 350V voltage rating.
- Operates reliably between -55°C and 125°C.
- Mounts through hole with straight orientation for secure solder termination.
- Pins have high retention force ensuring mechanical stability once soldered.
- Ideal for industrial, telecommunications, medical, consumer electronics, and automotive applications.
Product Description
Molex 90120-0782 C-Grid III Series Straight Through Hole Pin Header with 22 contacts and 2.54 mm pitch is engineered for reliable, secure wire to board and board to board interconnections in electronics assemblies.
This single row, unshrouded header is constructed with polyester housing and brass contacts plated in gold to ensure excellent conductivity and corrosion resistance over long lifetimes. The breakaway design permits flexible sizing to suit specific PCB layouts.
Rated for 3A current and 350V voltage, it can operate effectively within a wide temperature range from -55°C to 125°C, suitable for demanding industrial environments and consumer electronics alike.
The straight orientation and through hole mount provide strong mechanical stability once soldered, with tail pin length of 2.9 mm and mating pin length of 6.75 mm ensuring firm mating. The high retention force of pins ensures secure and durable connections essential for reliable performance in servers, medical devices, industrial equipment, and automotive safety circuits.
Designed for board to board and wire to board applications. Breakaway feature for customizable lengths. High retention force for secure mating connection. Stable solder termination and mechanical strength. Gold plated brass contacts prevent corrosion.
Polyester housing for robust insulation and durability. Supports up to 3A current and 350V voltage rating. Unshrouded design for compact PCB layout. Wide temperature operating range.
The Molex C-Grid III series is widely used across industrial, medical, telecommunications, computer, and automotive electronics sectors requiring dependable PCB connector solutions. This 90120-0782 model provides a balance of performance, flexibility, and reliability with industry-standard 2.54 mm pitch spacing.
Explore more from Molex products and PCB header connectors at EnvMart for your electronic component needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 3A and a voltage of 350V.
The pitch size of this pin header is 2.54 mm.
It operates reliably within a temperature range of -55°C to 125°C.
The housing is made of polyester, and the contacts are brass plated in gold for conductivity and corrosion resistance.
This model features 22 contacts.
It uses solder termination for secure connections.
The tail pin length is 2.9 mm.
This model is unshrouded, allowing for a more compact PCB layout.
The orientation of this pin header is straight, which aids in secure solder termination.
It is designed for board to board and wire to board connections in industrial, telecommunications, medical, consumer electronics, and automotive applications.
The maximum operating temperature for this pin header is 125°C.
This model supports a wire-to-board connector system.
