Molex C-Grid III Series Straight Through Hole Pin Header 28 Contacts 2.54 mm Pitch 2 Row Unshrouded 90131-0774

Free Delivery in India | Lowest Global Shipping Charges

Molex C-Grid III Series Straight Through Hole Pin Header 28 Contacts 2.54 mm Pitch 2 Row Unshrouded 90131-0774

Name: Molex C-Grid III Series Straight Through Hole Pin Header 28 Contacts 2.54 mm Pitch 2 Row Unshrouded 90131-0774
Brand: Molex
SKU: 206744
Price: 5.44 USD
Availability: InStock



Category PCB Pin Header Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	350V
Brand	Molex
Orientation	Straight
Current	3A
Mount Type	Through Hole
Housing Material	Polyester
Contact Material	Brass
Series	C-Grid III
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	28
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board
Tail Pin Length	2.9mm
Mating Pin Length	6.75mm

Key Features

Designed for board to board and wire to board applications.
Features a breakaway design for flexible sizing.
High pin retention force ensures secure mating connections.
Constructed with polyester housing and brass contacts plated with gold.
Supports operating voltage up to 350V and current up to 3A.
Suitable for operating temperatures from -55°C to 125°C.
Male contact gender with through hole mount type.
Tail pin length is 2.9 mm and mating pin length is 6.75 mm for reliable connection.

Product Description

Molex 90131-0774 C-Grid III Series Straight Through Hole Pin Header is a reliable PCB connector designed for demanding industrial and electronic applications requiring a secure connection. Featuring 28 male contacts arranged in 2 rows with a 2.54 mm pitch, this unshrouded header is suitable for both board to board and wire to board connection systems.

The connector uses a high-quality polyester housing paired with brass contacts plated in gold to ensure durability, corrosion resistance, and optimal conductivity. Its breakaway design allows for easy customization to fit specific PCB layouts, enhancing design flexibility.

Rated for an operating voltage of 350V and current capacity of 3A, it operates reliably at temperatures ranging from -55°C to 125°C, making it suitable for industrial, medical, telecommunications, automotive safety, and consumer electronics systems.

The through-hole mounting ensures strong mechanical stability once soldered, while the high retention force of the pins guarantees a secure mating with corresponding C-Grid III series sockets and crimp housings.

Designed for board to board and wire to board applications. Breakaway feature offers design flexibility. High pin retention force ensures secure mechanical connection. Polyester housing and brass contacts with gold plating provide durability and conductivity.

Compact 2.54 mm pitch with 2 rows and 28 contacts. Supports operating voltage up to 350V and current up to 3A. Operating temperature range: -55°C to 125°C. Through hole mounting type for mechanical stability. Ideal for industrial, computer, medical, telecommunications, and automotive electronics.

This Molex C-Grid III series header is compliant with standard industry requirements and is widely used in desktop computers, servers, monitors, medical equipment, white goods, industrial machinery, and automotive safety systems.

Discover more PCB Pin Header solutions and related connectors in the Electronics & Electricals category at EnvMart.
