Molex C-Grid III Series Straight Through Hole Pin Header 30 Contacts 2.54 mm Pitch 2 Row Unshrouded 90131-0135

The Molex 90131-0135 C-Grid III Series Straight Through Hole Pin Header is a high-quality 30-contact PCB header designed with a 2.54 mm pitch and two rows arranged in an unshrouded, straight orientation. Manufactured using durable polyester for the housing and brass contacts plated with tin, this pin header is engineered for excellent electrical performance and mechanical stability after soldering.

Its through-hole mount type and wire-to-board connector system make it suitable for a wide range of industrial and commercial applications, including computers, medical devices, telecommunications equipment, and automotive electronics. This header operates safely within a temperature range spanning from -55°C to 125°C and supports a maximum voltage of 350 volts and current of 3 amperes, meeting stringent industry requirements.

The breakaway design enhances design flexibility allowing the header to be sized as per application needs. With a tail pin length of 2.9 mm and mating pin length of 6.75 mm, it ensures secure and reliable interconnections. The high pin retention force provides strong mechanical stability, critical in demanding operational environments.

Applications for this connector include board-to-board and wire-to-board setups within industrial equipment, servers, desktop PCs, monitors, medical instruments, telecommunications hardware, automotive safety electronics, and other industrial automation systems.

This pin header is designed for through-hole mounting and wire-to-board connector systems. The housing is made of durable polyester material ensuring reliability. Contacts are made of brass with tin plating for optimal conductivity.

The component supports a maximum voltage rating of 350V and maximum current of 3A. It features a breakaway design providing design flexibility during assembly. Suitable operating temperature ranges from -55°C to 125°C for diverse industrial applications.

The header has a tail pin length of 2.9mm and mating pin length of 6.75mm for secure connections. This component provides high mechanical stability once soldered to printed circuit boards. Ideal for board-to-board and wire-to-board interconnections in industrial, computer, telecommunications, medical, and automotive sectors.
