Molex C-Grid III Series Straight Through Hole Pin Header, 48 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded 90131-0944

Free Delivery in India | Lowest Global Shipping Charges

Molex C-Grid III Series Straight Through Hole Pin Header, 48 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded 90131-0944

Name: Molex C-Grid III Series Straight Through Hole Pin Header, 48 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded 90131-0944
Brand: Molex
SKU: 206742
Price: 11.75 USD
Availability: InStock



Category PCB Pin Header Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	350V
Brand	Molex
Orientation	Straight
Current	3A
Mount Type	Through Hole
Housing Material	Polyester
Contact Material	Brass
Series	C-Grid III
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	48
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board
Tail Pin Length	6.75mm
Mating Pin Length	2.9mm

Key Features

This pin header is unshrouded for easy insertion and soldering.
Constructed with brass contacts gold plated for reliable conductivity and corrosion resistance.
Housing is made of durable polyester material ensuring mechanical stability.
Designed for through-hole mounting with a solder termination type for secure PCB connection.
Rated for 3 amperes current and 350 volts operating voltage with temperature range from -55 to 125°C.
Features high pin retention force to maintain secure mating in board to board and wire to board applications.
Breakaway design allows cutting to custom sizes for flexible PCB layouts.
Suitable for diverse industrial, computer, medical, telecommunications, and automotive electronic equipment.

Product Description

Molex 90131-0944 C-Grid III Series Straight Through Hole Pin Header is engineered for electronic assembly demanding reliable board connections. This model includes 48 male contacts arranged in 2 rows with a 2.54 mm standard pitch to interface with compatible PCB sockets and wire housings.

The brass contacts are gold plated to maximize electrical conductivity and resist corrosion over long-term industrial and commercial use. The header uses a polyester housing that provides durable insulation and mechanical robustness required in industrial, medical, and consumer electronic applications.

This pin header is unshrouded, enabling straightforward insertion and solder termination via a through-hole mount. The design supports 3A current capacity and withstands voltages up to 350V within an operating temperature range from -55°C to 125°C, making it suitable for demanding electronic environments.

Featuring a breakaway design, the header can be customized by cutting to size, offering design flexibility in PCB arrangements. The high retention force of the pins ensures secure mating and mechanical stability after soldering on the PCB.

Common applications include desktop PCs, servers, medical devices, telecommunications systems, white goods, exchange stations, industrial machinery, and automotive safety electronics. Its robust construction and standardized pitch make it compatible with other C-Grid III series connectors for board to board and wire to board interfacing.

This product supports a secure connection in high-reliability applications. The breakaway feature allows versatile PCB layout customization. Durable materials provide long service life with stable electrical performance.

Wide temperature range enhances suitability for various operating environments. Industry-wide compatibility with Molex C-Grid III series connectors and sockets. Explore our extensive range of electronic connectors and components at EnvMart for your industrial and manufacturing needs.
