Molex Micro-Fit 3.0 Series Straight Surface PCB Header 12 Contacts 3 mm Pitch 2 Row Shrouded 43045-1220

Molex 43045-1220 Micro-Fit 3.0 Series Straight Surface PCB Header features a 12-contact configuration arranged in two rows with a precise 3 mm pitch. Designed for wire-to-board applications, this shrouded header connector supports up to 5A current carrying capacity, making it a compact and reliable solution for low to mid power electronic circuits.

The housing is made of high temperature thermoplastic material capable of withstanding IR reflow soldering temperatures up to 265°C, ensuring reliable manufacturing processes. Brass contacts plated with gold offer excellent conductivity and protection against corrosion, while the solder tabs enable secure surface mounting on printed circuit boards.

Engineered for durability, this connector operates in a temperature range from -40°C to 125°C. The positive latching with locking ramp guarantees a secure mating connection, preventing accidental disconnections during usage. The fully isolated dual beam terminals provide reliable electrical contact and reduce the possibility of arcing within the housing.

This Micro-Fit 3.0 Series header is applicable in diverse industries including military commercial off-the-shelf solutions, solar power systems, consumer appliances such as dryers and washing machines, data communication equipment like routers and servers, medical devices, telecommunications, and gaming terminals.

Designed for compact power distribution, this Molex Micro-Fit 3.0 connector offers a space-efficient and robust interface ensuring dependable performance in various industrial and electronic assembly applications.

The connector supports a current rating of 5A for robust power distribution. Constructed with high temperature thermoplastic housing for durability during soldering. Features gold-plated brass contacts ensuring low resistance and corrosion protection.

Includes solder tabs for secure surface mounting on PCB boards. Operates reliably between -40°C to 125°C for broad temperature tolerance. Positive latching mechanism prevents accidental disconnection. Compact 3 mm pitch dual-row design saves PCB space.

Housing material meets UL 94V-0 standard for flame retardancy. Fully isolated dual beam terminals enhance electrical performance and reduce arcing. Explore the Electronics & Electricals category for a wide range of connectors and PCB Headers available at EnvMart to suit all industrial and commercial requirements.
