Molex KK 508 Series Straight Through Hole Pin Header 5 Contacts 5.08 mm Pitch 1 Row Unshrouded 10-08-1051
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 7A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | KK 508 |
| Termination Type | Solder |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Contact Plating | Tin |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3.94mm |
Key Features
- This pin header facilitates reliable board-to-board and wire-to-board connections.
- It features a straight orientation and is designed for through-hole mount type.
- The contacts are made of brass with tin plating ensuring good conductivity and corrosion resistance.
- Housing material is durable nylon for insulation and mechanical stability.
- The termination type is solder, with a tail pin length of 3.94 mm for secure PCB insertion.
- Operates within a temperature range of -40°C to 80°C, suitable for various industrial environments.
- Rated for 7 A current and 250 V voltage, making it ideal for standard electronic applications.
- The component is unshrouded, offering easier inspection and soldering access.
Product Description
Molex 10-08-1051 KK 508 Series Straight Through Hole Pin Header, featuring 5 contacts with a 5.08 mm pitch and single row configuration, is a robust electronic component designed for reliable board-to-board and wire-to-board interconnections. The connector is unshrouded with a straight orientation, making it suitable for applications requiring easy inspection and soldering.
Constructed with brass contacts plated with tin, the pin header offers excellent electrical conductivity and corrosion resistance. The housing is composed of high-quality nylon, providing electrical insulation and mechanical strength essential for industrial electronic assemblies.
This connector supports a current rating of 7 A and a voltage rating of 250 V, making it appropriate for moderate power electronic devices. Designed for through-hole mounting with solder termination and a tail pin length of 3.94 mm, it ensures a secure and stable connection on printed circuit boards (PCBs).
Operating temperature ranges from -40°C to 80°C, allowing deployment in diverse industrial, manufacturing, and electronic applications. This product mates with Molex 3001 and 5058 Series housings and 3002 Series PC Board connectors, offering compatibility in various connector systems.
This pin header facilitates reliable board-to-board and wire-to-board connections. Features brass contacts with tin plating for durability and conductivity. Housing made of nylon for strong insulation and mechanical stability.
Supports 7 A current and 250 V voltage specifications. Designed for through-hole mounting and solder termination type. Operates effectively within the temperature range of -40°C to 80°C. Unshrouded design enables easy inspection and soldering access.
Molex KK 508 Series pin headers are widely used in industrial electronics, manufacturing equipment, and PCB assembly, providing economical and dependable interconnect solutions. This product complements various industrial and laboratory applications requiring robust electrical connections.
Explore more advanced electronic components and connectors available to enhance your manufacturing and industrial assembly processes on EnvMart.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This pin header has a current rating of 7 A and a voltage rating of 250 V, making it suitable for standard electronic applications.
It features a pitch of 5.08 mm and includes 5 contacts in a single row configuration.
The contacts are made of brass with tin plating, while the housing is constructed from nylon, providing electrical insulation and mechanical stability.
The tail pin length is 3.94 mm, ensuring a secure connection when inserted into the PCB.
It operates effectively within a temperature range of -40°C to 80°C, suitable for various industrial environments.
This model is designed for through-hole mounting, which allows for stable connections on printed circuit boards.
This pin header is unshrouded, which facilitates easier inspection and soldering access during assembly.
The termination type for this pin header is solder, ensuring a reliable connection to the PCB.
It mates with Molex 3001 and 5058 Series housings and 3002 Series PC Board connectors, providing compatibility across various systems.
This pin header is widely used in industrial electronics, manufacturing equipment, and PCB assembly, providing reliable interconnect solutions.
The orientation of this pin header is straight, which is typical for applications requiring direct connections.
The country of origin for this pin header is India.
