Molex KK 396 Series Straight Through Hole Pin Header, 3 Contact(s), 3.96 mm Pitch, 1 Row, Unshrouded 26-61-4030
Specifications
| Country of Origin | Mexico |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 7A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | KK 396 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Contact Plating | Tin |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.56mm |
Key Features
- Features a 3.96 mm pitch for precise spacing between contacts.
- Consists of 3 straight, male contacts with unshrouded design.
- Through hole mount type allows secure soldered connections on PCBs.
- Contact material is brass plated with tin for corrosion resistance.
- Rated for electrical current up to 7A and voltage up to 250V.
- Operates reliably in temperature ranges from -40°C to 105°C.
- Housing is made from durable polyester for insulation and stability.
- Tail pin length of 3.56 mm facilitates secure soldering.
Product Description
Molex 26-61-4030 KK 396 Series Straight Through Hole Pin Header is a precision electronic connector component designed for wire-to-board applications. Featuring 3 straight male contacts aligned in a single row, this unshrouded header provides a 3.96 mm pitch tailored for reliable PCB connectivity.
The contacts are constructed from high-quality brass with tin plating, ensuring optimal conductivity and resistance to oxidation. The polyester housing material offers excellent mechanical strength and electrical insulation. This connector operates at voltages up to 250V and currents up to 7A, suitable for varied industrial electronics applications.
Designed for through-hole mounting, its tail pin length of 3.56 mm allows secure and stable solder joints onto printed circuit boards. The connector functions properly within a wide temperature range from -40°C to 105°C, making it suitable for demanding environmental conditions encountered in industrial, manufacturing, and electronic assembly sectors.
This Molex KK 396 Series header mates with standard Molex housings and PC board connectors such as the 2139, 3069, 6442, and 41695 Series, enabling flexible system integration. It finds use in diverse applications including electronics manufacturing, automation control systems, and power distribution modules.
Features a 3.96 mm pitch for precise spacing between contacts. Consists of 3 straight, male contacts with unshrouded design. Through hole mount type allows secure soldered connections on PCBs. Contact material is brass plated with tin for corrosion resistance.
Rated for electrical current up to 7A and voltage up to 250V. Operates reliably in temperature ranges from -40°C to 105°C. Housing is made from durable polyester for insulation and stability. Tail pin length of 3.56 mm facilitates secure soldering.
Compatible with various Molex KK series connectors and housings. Manufactured in Mexico under Molex quality standards ensuring consistency.
Ideal for industrial and electronic component assembly applications, this pin header enhances connection reliability and simplifies PCB interfacing. Explore more Molex components for comprehensive connector solutions in electronics manufacturing on EnvMart.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a maximum current of 7A.
It can handle voltages up to 250V.
The pitch of this pin header is 3.96 mm.
The tail pin length is 3.56 mm, facilitating secure soldering.
The contacts are made of brass with tin plating, and the housing is made from polyester.
It operates reliably within a temperature range of -40°C to 105°C.
This model consists of 3 straight male contacts.
This pin header features an unshrouded design.
It uses a through-hole mounting type for secure soldered connections on PCBs.
It is compatible with standard Molex housings and PC board connectors such as the 2139, 3069, 6442, and 41695 Series.
This product is manufactured in Mexico under Molex quality standards.
The termination type for this model is solder.
