Molex KK 396 Series Straight Through Hole Pin Header, 12 Contacts, 3.96 mm Pitch, 1 Row, Unshrouded 26-48-1121
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 7A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | KK 396 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Contact Plating | Tin |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 4.37mm |
| Mating Pin Length | 11.43mm |
Key Features
- Provides a reliable solution for PCB board-to-board or wire-to-board connections.
- Unshrouded, single-row design for easy access and insertion.
- Supports up to 7A current and 250V voltage ratings.
- Straight orientation suitable for vertical mounting in circuit boards.
- Features tin-plated brass contacts and polyester housing for robust electrical performance.
- Solder termination ensures secure attachment to PCB.
- Rated for operation from -40°C to 105°C, meeting industrial requirements.
- Compatible with Molex KK 396 series sockets for modular design flexibility.
Product Description
The Molex KK 396 Series Pin Header, model 26-48-1121, is engineered for demanding PCB applications where reliable, high-current connectivity is essential. Designed with 12 male contacts in a single row, spaced at a 3.96 mm pitch, this header is optimized for both board-to-board and wire-to-board use cases in industrial electronics.
This pin header is unshrouded for convenient insertion and removal, allowing flexibility in circuit design, maintenance, and prototyping. The straight orientation facilitates vertical mounting in printed circuit boards, making it a preferred choice for compact assemblies requiring precise alignment and robust connections.
Constructed with tin-plated brass contacts and a polyester housing, the product combines excellent electrical conductivity with mechanical durability. The KK 396 Series supports a 7A current and 250V maximum voltage rating, ensuring safe performance for power and signal transmission in commercial, laboratory, and industrial environments.
Provides a reliable solution for PCB board-to-board or wire-to-board connections. Unshrouded, single-row design for easy access and insertion. Supports up to 7A current and 250V voltage ratings. Straight orientation suitable for vertical mounting in circuit boards.
Features tin-plated brass contacts and polyester housing for robust electrical performance. Solder termination ensures secure attachment to PCB. Rated for operation from -40°C to 105°C, meeting industrial requirements. Compatible with Molex KK 396 series sockets for modular design flexibility.
Industrial uses include electronics manufacturing, laboratory test instrumentation, commercial device prototyping, control panels, and embedded systems requiring reliable and modular PCB header solutions. The solder termination enhances long-term stability in demanding environments.
Ideal for engineers and designers seeking a high-quality PCB header for versatile connector system integrations. Explore more Molex PCB connectors and headers in the Electronics & Electricals category on EnvMart.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current rating of 7A.
It has a maximum voltage rating of 250V.
The contacts are spaced at a pitch of 3.96 mm.
The pin header features solder termination for secure attachment to the PCB.
It is constructed with tin-plated brass contacts and a polyester housing.
It is rated for operation from -40°C to 105°C.
This model features 12 male contacts.
It has a straight orientation suitable for vertical mounting in circuit boards.
Yes, it is compatible with Molex KK 396 series sockets for modular design flexibility.
The mounting type is through hole, allowing for secure installation on PCBs.
It is suitable for board-to-board and wire-to-board connections in industrial electronics.
The tail pin length is 4.37 mm.
