Molex KK 254 Series Right Angle Through Hole Pin Header, 7 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 22-12-4072
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 4A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | KK 254 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 7 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.8mm |
| Mating Pin Length | 2.54mm |
Key Features
- Unshrouded, 1-row pin header for versatile PCB applications.
- Right angle orientation optimizes PCB layout and connections.
- Brass contacts plated with gold for enhanced conductivity and corrosion resistance.
- Nylon 6/6 UL 94V-0 housing material delivers durability and flame resistance.
- Supports a current rating of 4 A and voltage rating of 250 V.
- Contact tail pin length of 3.8 mm ensures stable solder connections.
- Operating temperature range from -40°C to 105°C suitable for diverse environments.
- Through hole mount type provides strong mechanical stability on PCB.
Product Description
Molex 22-12-4072 KK 254 Series Right Angle Through Hole Pin Header is a high-quality electronic component designed for wire-to-board connections in electronic circuits. It features 7 male contacts arranged in a single row with a standard 2.54 mm pitch suitable for a wide range of PCB designs.
The pin header uses gold-plated brass contacts that ensure excellent electrical conductivity and corrosion resistance, enhancing long-term performance. The housing is made from Nylon 6/6 with UL 94V-0 rated flame retardancy, providing durability and safety in demanding environments.
This right angle header allows optimal PCB layout by enabling perpendicular connections. With a tail pin length of 3.8 mm, it ensures strong and stable solder joints. The component supports a rated current of 4 A and operating voltage of 250 V, making it ideal for low to moderate power electronic applications.
The device operates reliably between -40°C and 105°C, accommodating industrial, commercial, and consumer electronics temperature requirements. It mounts through hole for robust mechanical stability and mates typically with KK 254 Series 7395 connectors, featuring a friction lock for secure connections.
Unshrouded 1-row, 7-contact right angle pin header. Gold-plated brass contacts for superior conductivity. Durable Nylon 6/6 housing with flame retardant properties. Supports 4 A current and 250 V voltage ratings. Temperature range from -40°C to 105°C.
Through hole mounting ensures mechanical reliability. Tail pin length of 3.8 mm for stable soldering. Compatible with 7395 series friction lock connectors.
This Molex pin header is widely used in electronics manufacturing, industrial control systems, and other applications requiring reliable PCB interconnects. It is suitable for industrial, laboratory, manufacturing, and consumer electronics environments.
Browse other quality electronic connectors and components at EnvMart for a complete solution to your PCB hardware needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 4 A and a voltage rating of 250 V, making it suitable for low to moderate power electronic applications.
The pitch size is 2.54 mm, which is standard for many PCB designs.
The contacts are made of brass and are gold-plated to enhance conductivity and corrosion resistance.
The tail pin length is 3.8 mm, ensuring stable solder connections on the PCB.
It operates reliably within a temperature range of -40°C to 105°C, accommodating various environments.
It features a through hole mount type, providing strong mechanical stability on the PCB.
This model has 7 male contacts arranged in a single row.
The housing is made from Nylon 6/6, which is UL 94V-0 rated for flame resistance and durability.
It utilizes a wire-to-board connector system, suitable for various electronic applications.
This model is unshrouded, allowing for versatile PCB applications and connections.
It has a right angle orientation, optimizing PCB layout and connections.
It typically mates with KK 254 Series 7395 connectors, featuring a friction lock for secure connections.
