Texas Instruments Operational Amplifier 100 MHz 8-Pin MSOP 3-5.5V OPA2354AIDGKT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 0.97mm |
| Length | 3mm |
| Model | OPA2354AIDGKT |
| Width | 3mm |
| Mount Type | Surface |
| Series | OPA2354 |
| Output Current | 100mA |
| Maximum Operating Temperature | 125°C |
| Package Type | MSOP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 100MHz |
| Input Bias Current | ±50 pA |
| Vos - Input Offset Voltage | ±10 mV |
| Slew Rate | 150V/μs |
Key Features
- Operates at a supply voltage range of 3 V to 5.5 V.
- Dual channel configuration suitable for varied amplification tasks.
- Input bias current of ±50 pA ensures high precision.
- Slew rate of 150 V/μs enables fast signal response.
- Complies with RoHS standards for environmental safety.
- Optimized for automotive use, meeting AEC-Q100 standards.
- Compact size with dimensions 3mm length, 3mm width, and 0.97mm height.
- High output current of up to 100 mA for driving loads.
Product Description
Texas Instruments OPA2354AIDGKT is a high-performance operational amplifier designed for surface mount applications. It offers a gain bandwidth product of 100 MHz with dual channel configuration in a compact 8-pin MSOP package, operating efficiently at supply voltages ranging from 3 V to 5.5 V.
This operational amplifier is notable for its low input bias current of ±50 pA and a rapid slew rate of 150 V/μs, making it suitable for precision analog signal amplification in demanding circuits.
The device complies with RoHS directives, ensuring environmental and safety standards are met. Certified to automotive AEC-Q100 standards, it is reliable for automotive electronics use.
With a compact form factor measuring 3mm in length, 3mm in width, and 0.97mm in height, the OPA2354AIDGKT is ideal for space-constrained designs.
It supports a wide operating temperature range of -40°C to 125°C to function reliably in industrial, automotive, and commercial environments. The device can deliver an output current of up to 100 mA, allowing it to drive various loads effectively.
Operates on a dual channel 8-pin MSOP package. Gain bandwidth product of 100 MHz for high-speed amplification. Low input bias and offset current for enhanced precision. Wide voltage supply range of 3 V to 5.5 V. Automotive grade compliance with AEC-Q100 standard.
Compact dimensions for integration in compact electronic assemblies.
Useful for industrial, automotive, laboratory, and electronic instrumentation applications, the OPA2354AIDGKT offers efficient, precise amplification performance. Explore more Operational Amplifiers in the Electronics & Electricals category at EnvMart for your design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 100 MHz, allowing for high-speed amplification in various applications.
It operates efficiently within a supply voltage range of 3 V to 5.5 V.
This operational amplifier can deliver an output current of up to 100 mA, suitable for driving various loads.
The OPA2354AIDGKT has compact dimensions of 3 mm in length, 3 mm in width, and 0.97 mm in height.
It features a low input bias current of ±50 pA, which enhances precision in analog signal amplification.
The slew rate of this model is 150 V/μs, enabling fast signal response.
It can function reliably in a wide operating temperature range of -40°C to 125°C.
This operational amplifier is housed in an 8-pin MSOP package, designed for surface mount applications.
Yes, it complies with RoHS standards, ensuring it meets environmental safety regulations.
It is certified to the AEC-Q100 standard, making it suitable for automotive applications.
This operational amplifier features a dual channel configuration, making it versatile for various amplification tasks.
The input offset voltage is specified at ±10 mV, contributing to its precision in amplification tasks.
