Relpol PCB Power Relay 9V DC Coil 8A Switching Current 1 CO RM96-1011-35-1009

Free Delivery in India | Lowest Global Shipping Charges

Relpol PCB Power Relay 9V DC Coil 8A Switching Current 1 CO RM96-1011-35-1009

Name: Relpol PCB Power Relay 9V DC Coil 8A Switching Current 1 CO RM96-1011-35-1009
Brand: Relpol
SKU: 202400
Price: 6.1 USD
Availability: InStock



Category Power Relay Brand Relpol Condition New

Specifications

Country of Origin	Poland
Brand	Relpol
Height	16.2mm
Length	30mm
Model	RM96-1011-35-1009
Width	10mm
Mount Type	PCB
Contact Material	Silver Alloy
Series	RM96
Maximum Operating Temperature	80°C
Contact Configuration	1 CO
Minimum Operating Temperature	-40°C
Switching Current	8A
Terminal type	PCB Pin
Contact Resistance	100mΩ
Standards/Approvals	EAC, RoHS
Coil Resistance	360Ω
Coil Voltage	9V dc
Switching DC Voltage	24V dc
Switching AC Voltage	440V
Coil Power	300mW

Key Features

Designed for PCB mounting with PCB pin terminals for secure installation.
Supports switching voltages up to 24V DC and 440V AC for versatile use.
Compact dimensions measuring 30mm length, 10mm width, and 16.2mm height.
Operates reliably within a temperature range of -40°C to 80°C.
Silver alloy contacts ensure low contact resistance of 100mΩ for efficient switching.
Coil resistance is 360Ω with a power consumption of 300mW providing energy-efficient operation.
Conforms to EAC and RoHS standards, indicating compliance with regulatory requirements.
Manufactured in Poland ensuring high-quality production standards.

Product Description

Relpol RM96-1011-35-1009 PCB Power Relay is a miniature relay designed for general-purpose applications requiring reliable switching performance. It is specifically engineered for PCB mounting and comes with PCB pin terminals to facilitate secure integration in electronic circuits.

This power relay includes a 9V DC coil that energizes the contact mechanism to switch currents up to 8A. It is rated for switching voltages of 24V DC and 440V AC, making it suitable for a broad range of electrical and automation uses such as household appliances, automation systems, electronic equipment, telecommunications, instrumentation, and remote control devices.

With compact dimensions of 30mm in length, 10mm in width, and 16.2mm in height, it is easy to incorporate into densely packed PCB layouts. The device is capable of reliable operation across a wide temperature range from -40°C to 80°C, ensuring stable performance in harsh environments.

The contact material is a high-quality silver alloy that delivers low contact resistance at 100mΩ, ensuring efficient electrical conduction and durability under switching loads. The coil resistance of 360Ω and low coil power of 300mW also contribute to its energy efficiency during operation.

This relay series complies with EAC and RoHS standards, confirming adherence to relevant safety and environmental regulations. Produced in Poland, it reflects quality manufacturing and engineering excellence.

Designed for PCB mounting with secure PCB pin terminals. Supports switching 8A current up to 440V AC and 24V DC. Compact size of 30×10×16.2 mm for space-constrained applications. Works effectively between -40°C and 80°C ambient temperatures.

Silver alloy contacts with low resistance optimize switching efficiency. Low coil power consumption at 300mW enhances energy savings. Meets EAC and RoHS standards for safety and compliance. Suitable for electrical appliances, automation, telecom, and instrumentation.
