Murata Power Solutions 1W SIP Unregulated Isolated DC-DC Converter Through Hole 85°C Max Temp NME0505SC

Murata Power Solutions NME0505SC is a high-efficiency, 1 Watt Single Inline Package (SIP) DC-DC converter designed for unregulated isolated power conversion. This through hole mounted module supports a nominal output voltage of 5V DC and an output current of 200mA, with an input voltage operating range of 4.5V to 5.5V DC. Its compact DIP package with 4 pins facilitates easy insertion and soldering on PCB assemblies.

This module achieves 69% efficiency and includes 1kV DC isolation voltage, providing robust protection in industrial and commercial electronic applications. The ripple and noise voltage is kept low at 40mV peak-to-peak, ensuring stable output voltage for sensitive electronic circuits.

Constructed with UL 94V-0 rated plastic material, the NME series package meets flame retardancy standards suitable for manufacturing environments. The converter supports operating temperatures from -40°C to 85°C, making it suitable for various demanding environments including industrial control, telecom, instrumentation, and embedded power supply systems.

The compact dimensions of 11.48mm (L) x 11.6mm (W) x 10mm (D) along with a lightweight of 1.3 grams enable integration into space-limited systems. Its no external components required design simplifies system architecture, reducing overall bill of materials and assembly time.

The product complies with RoHS environmental directives, supporting green manufacturing initiatives and electrical safety compliance. Offers a single output voltage of 5V DC at 200mA current capacity. Operates within an input voltage range of 4.5V to 5.5V DC.

Features a through hole DIP package suitable for PCB mounting. Ripple and noise level is maintained at 40mV peak-to-peak ensuring signal integrity. Isolation voltage rated at 1kV DC provides electrical separation between input and output.

The compact SIP4 plastic package measures approximately 11.48mm length by 11.6mm width and 10mm depth. Efficiency is rated at 69%, optimized for low power consumption applications. Designed for harsh environments with operating temperature from -40°C to 85°C.

Complies with RoHS standards for environmental and safety regulations. Lightweight at 1.3 grams, ideal for space-constrained electronic equipment.

This DC-DC Converter is suitable for industrial automation, instrumentation, telecommunications, and embedded systems where isolated low-power DC conversion is necessary. Murata Power Solutions provides robust and reliable power components that help engineers and designers deliver efficient power solutions in compact, durable forms.
