TE Connectivity DIN Rail Force Guided Relay 9V DC Coil Voltage, 2-Pole, DPDT V23047A1009A501

TE Connectivity V23047A1009A501 is a DIN Rail Force Guided Relay engineered for precise switching applications with a 9V DC coil voltage and dual pole double throw (DPDT) contact configuration. Its design is optimized to meet the demands of industrial and automation environments.

Constructed for DIN rail mounting, this relay facilitates straightforward and secure installation in control panels and electronic assemblies. The coil resistance of 116Ω and coil power rating of 698mW ensure efficient energy consumption and reliable coil operation.

The relay employs silver alloy contacts for superior electrical conductivity and mechanical endurance, offering dependable switching performance. Its operating temperature range from -25°C to 70°C makes it adaptable for various industrial and domestic applications including interface systems, automation controls, security lighting, and heating systems.

The solder-type terminal connections provide robust and long-lasting electrical contact. Physically, this relay measures 25.5mm in height, 29mm in length, and 12.6mm in depth, making it compact for integration into equipment and systems with limited space.

Electrical isolation is reinforced by 4kVrms coil to contact isolation, enhancing safety and resilience against voltage spikes or surges. Manufactured in Czech Republic, the product adheres to strict quality controls and standards.

Typical uses include electrical control systems in industrial machinery, automation equipment, and other areas requiring force guided relay switching. It is part of the SR2M Series by TE Connectivity, known for reliability and performance in power relay applications.

This relay is designed for DIN rail mounting to ensure secure installation. It features a coil resistance of 116Ω for stable operation. The coil power consumption is 698mW, optimizing energy use. The relay contacts are made with silver alloy for enhanced conductivity and durability.

Operating temperature range spans from -25°C to 70°C, suitable for various environments. Terminal connections are solder type for reliable electrical contact. Dimensions measure 25.5mm height, 29mm length, and 12.6mm depth for compact integration.

Coil to contact isolation provides 4kVrms protection ensuring electrical safety. The product is manufactured in Czech Republic, ensuring high quality standards. Explore the TE Connectivity range and other Force Guided Relays on EnvMart for high-quality electrical and automation components.
