TDK SMT Shielded Wirewound Surface Mount Inductor with Ferrite Core 470 μH ±20% 800 mA IDC B82477G4474M000
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 8mm |
| Length | 12.8mm |
| Model | B82477G4474M000 |
| Depth | 12.8mm |
| Packaging | 24 mm Blister Tape |
| Series | B82477-G4 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Ferrite |
| Inductance | 470μH |
| Standards/Approvals | RoHS, IEC 60068-2-58 |
| Package/Case | SMT |
| Maximum DC Current | 800mA |
| Maximum DC Resistance | 790mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Soldered |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Magnetically shielded ferrite core with wirewound enamel copper coil construction.
- Designed for surface mount technology (SMT) applications.
- Maximum DC resistance of 790 mΩ ensuring low power loss.
- Complies with automotive standard AEC-Q200 for reliability.
- Operating temperature range from -55°C to 125°C.
- Packaging includes 24 mm blister tape for efficient machine insertion.
- Soldered termination style suitable for surface mounting on PCBs.
- RoHS compliant and meets IEC 60068-2-58 environmental standards.
Product Description
TDK B82477G4474M000 is a surface mount technology (SMT) shielded wirewound inductor designed with a ferrite core and enamel copper wire construction. It offers an inductance of 470 μH with a tolerance of ±20% combined with a maximum DC current rating of 800 mA. This magnetically shielded inductor ensures minimal electromagnetic interference, making it suitable for high-reliability electronics including automotive systems adhering to AEC-Q200 standards.
This component features a low maximum DC resistance of 790 mΩ, contributing to enhanced efficiency in filtering and DC-DC converter circuits. It can operate reliably in harsh environments with a temperature range spanning from -55°C up to 125°C. The device is compact, measuring 12.8 mm in length, 8 mm in height, and 12.8 mm in depth, fitting well within dense PCB layouts.
The soldered termination style supports robust surface mounting and is packaged in 24 mm blister tape reels optimized for automated assembly. Additionally, it is RoHS compliant and meets IEC 60068-2-58 standards, confirming robustness against environmental stresses. This inductor series is widely used for supply voltage filtering, power management, and noise suppression in industrial, automotive, and consumer electronics applications.
Magnetically shielded ferrite core with enamel copper wire winding for high performance. Designed for SMT with soldered terminals to ensure assembly reliability. Complies with automotive and environmental standards for industrial quality.
Compact dimensions suitable for dense PCB layouts. Wide operating temperature range supports various industrial applications. Packaging designed for increased manufacturing efficiency. Ideal for filtering, DC-DC converters and automotive electronic circuits.
Explore our Electronics Components category for more Surface Mount Inductors and other electronic passive components for all industrial, laboratory, automotive, and commercial uses at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 470 μH with a tolerance of ±20%.
The maximum DC current rating for this unit is 800 mA.
It measures 12.8 mm in length, 8 mm in height, and 12.8 mm in depth.
The maximum DC resistance is 790 mΩ, which helps ensure low power loss.
It can operate reliably within a temperature range of -55°C to 125°C.
This inductor features a ferrite core, which contributes to its magnetically shielded design.
It is packaged in 24 mm blister tape, optimized for efficient machine insertion during assembly.
It features a soldered termination style suitable for surface mounting on PCBs.
It complies with the automotive standard AEC-Q200, ensuring reliability in automotive applications.
It is RoHS compliant and meets IEC 60068-2-58 environmental standards.
This inductor is suitable for supply voltage filtering, power management, and noise suppression in various electronics applications.
It has a wirewound construction with enamel copper wire, enhancing its performance in electronic circuits.
