Phoenix Contact PLC-RSC- 24DC/ 1/MS/ACT Series Electromechanical Interface Relay DIN Rail Mount 24V DC Coil SPST 6A 2909661
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | Phoenix Contact |
| Height | 80mm |
| Length | 94mm |
| Model | 2909661 |
| Width | 6.2mm |
| Mount Type | DIN Rail |
| Contact Material | Silver Alloy |
| Series | PLC-RSC- 24DC/ 1/MS/ACT |
| Maximum Operating Temperature | 60°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 6A |
| Terminal type | Screw |
| Standards/Approvals | EU RoHS, CHINA RoHS, CE, UKCA, IEC 60947-5-1, DNV GL, EU REACH SVHC, cULus Listed, IEC 60664 |
| Coil Voltage | 24V dc |
| Coil Current | 15.3mA |
| Switching DC Voltage | 250V dc |
| Switching AC Voltage | 250V ac |
Key Features
- Designed for DIN rail NS 35/7.5 mounting for easy integration in control panels.
- Compact relay module with screw terminal block ensures secure electrical connections.
- Coil current is 15.3 mA, suitable for efficient power usage in automation systems.
- Can switch AC and DC voltages up to 250V, providing versatile application options.
- Durable silver alloy contact material ensures reliable switching performance.
- Operating temperature range from -40°C to 60°C supports extreme environmental conditions.
- Complies with multiple international standards including EU RoHS, CE, IEC 60947-5-1, and cULus for quality assurance.
Product Description
Phoenix Contact 2909661 PLC-RSC- 24DC/ 1/MS/ACT Series electromechanical interface relay is engineered for industrial automation applications requiring reliable signal switching and isolation. The relay features a 24V DC coil with a low coil current of 15.3 mA, minimizing energy consumption during operation. Designed for mounting on DIN rails, the compact device measures 94mm length, 80mm height, and 6.2mm width, enabling space-saving installation in control panels.
This relay offers a single-pole single-throw (SPST) contact configuration rated for a switching current of 6A, capable of handling both AC and DC voltages up to 250V. Its silver alloy contacts provide excellent electrical conductivity and durability, ensuring long service life under demanding industrial conditions.
Suitable for use in automation, manufacturing, building control systems, and electrical equipment monitoring, the interface relay provides electrical isolation between control systems and peripherals while amplifying and switching signals as required. The device supports the DIN rail NS 35/7.5 mounting system and employs screw-type terminals for reliable wiring connections.
Designed and manufactured in Germany, this relay complies with stringent standards such as EU RoHS, CHINA RoHS, CE, UKCA, IEC 60947-5-1, DNV GL, EU REACH SVHC, and cULus Listing, assuring high quality and environmental compliance.
Designed for DIN rail NS 35/7.5 mounting. Screw terminal block ensures secure connections. 24V DC coil voltage with 15.3mA coil current reduces power consumption. SPST contact configuration rated for 6A switching current.
Switching capability up to 250V AC/DC increases versatility. Silver alloy contacts enhance durability and conductivity. Wide operating temperature range from -40°C to 60°C supports harsh environments. Complies with multiple international quality and safety standards.
This electromechanical Interface Relay is ideal for use in industrial automation, control panel assemblies, electrical isolation applications, power amplification, and frequency voltage adjustment systems. It enables reliable communication between automation equipment and system peripherals, contributing to efficient and safe process control.
Explore the range of high-quality relays and contactors available in the Electronics & Electricals category on EnvMart for your industrial automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay operates with a coil voltage of 24V DC.
It has a maximum switching current rating of 6A.
This relay features a single-pole single-throw (SPST) contact configuration.
The operating temperature range is from -40°C to 60°C.
The relay measures 94mm in length, 80mm in height, and 6.2mm in width.
It is designed for DIN rail NS 35/7.5 mounting.
The contacts are made of silver alloy, which enhances electrical conductivity and durability.
It can switch both AC and DC voltages up to 250V.
It complies with EU RoHS, CHINA RoHS, CE, UKCA, IEC 60947-5-1, DNV GL, EU REACH SVHC, and is cULus Listed.
The coil current is 15.3 mA, which helps minimize energy consumption during operation.
It employs screw-type terminals for secure electrical connections.
This model is suitable for industrial automation, control panel assemblies, and electrical isolation applications.
