Finder 48 Series Interface Relay, DIN Rail Mount, 12V DC Coil, SPDT Contact, 10A Switching Current 48.31.7.012.0050SPA

Finder 48.31.7.012.0050SPA is a 48 Series Interface Relay designed for robust industrial automation and control system applications. Featuring a 12V DC coil voltage and SPDT (Single Pole Double Throw) contact configuration, this relay is engineered for reliable switching in diverse electrical environments.

The relay is intended for DIN rail mounting, allowing easy installation and integration into control panels and machinery enclosures. Its compact size - measuring 15.8mm in length, 75.3mm in width, and 78.6mm in height - makes it suitable for tight panel spaces.

Electrically, the relay can switch currents up to 10 amps, supporting a switching AC voltage of 250V and DC voltage of 12V, enabling effective load management in automation circuits. The relay coil draws 41mA current and has a coil resistance of 292.68 Ω.

Constructed with high-quality silver alloy contacts, it delivers enhanced conductivity and durability, ensuring long operational life and minimal contact degradation. The device supports operating temperatures ranging from -40°C to +70°C, making it suitable for harsh industrial and manufacturing environments.

Connections are provided via screw terminals that ensure secure wiring and electrical continuity. This model meets CSA and CE approvals, ensuring compliance with international safety and quality standards.

This relay module is ideal for control panels, building automation systems, electrical distribution boards, and heavy machinery control such as hoists, cranes, and lifts. Its robust design also supports use in medical and dental equipment, illustrating its versatility.

Operates at 12V dc coil voltage for energy-efficient control. Features a Single Pole Double Throw (SPDT) contact configuration. Suitable for DIN rail mounting in electrical panels. Silver alloy contact material ensures high durability and conductivity.

Switching current rated for 10 amps for versatile load handling. Wide operating temperature range from -40°C to +70°C. Compact dimensions of 15.8mm length, 75.3mm width, and 78.6mm height. Screw-type terminals provide secure and reliable electrical connections.

Certified to CSA and CE standards for safety and quality assurance. Designed for industrial automation and control panel applications. Explore more relays and electrical components in our Electronics & Electricals category for reliable industrial solutions.
