Dold Interface Relay Module, DIN Rail, 24V AC Coil, 1 CO Contact, 16A Switching Current IK8701
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | Dold |
| Height | 89mm |
| Length | 58mm |
| Model | IK8701 |
| Width | 17.5mm |
| Mount Type | DIN Rail |
| Series | IK8701 |
| Maximum Operating Temperature | 45°C |
| Contact Configuration | 1 CO |
| Minimum Operating Temperature | -20°C |
| Switching Current | 16A |
| Standards/Approvals | CE |
| Coil Voltage | 24V ac |
| Switching AC Voltage | 230V ac |
| Dold IK8701 Series Interface Relay Module, DIN Rail, 24V Coil, 1 NOBrand | Dold |
Key Features
- Designed for DIN rail mounting, compatible with standard electrical panels.
- Supports 24V AC coil voltage for secure and reliable operation.
- Features a single changeover (CO) contact configuration for versatile switching.
- Rated for a maximum switching current of 16A and up to 230V AC.
- Compact dimensions with 17.5mm width, 58mm length, and 89mm height, ideal for space-constrained installations.
- Operating temperature range from -20°C to 45°C ensures stable performance.
- Complies with CE standards for industrial reliability and safety.
- Manual operation switch and clear switch position indication for easy maintenance.
Product Description
Dold IK8701.11 DC24V Interface Relay Module combines robust performance with compact design, ideal for industrial control panels and automation systems. This relay is engineered with a 24V AC coil and a single changeover (CO) contact configuration, capable of handling high switching currents up to 16A. It is optimized for DIN rail mounting, simplifying installation and integration into existing electrical enclosures.
Designed for DIN rail compatibility, facilitating quick installation in electrical and automation systems. Operates reliably on a 24V AC coil voltage, ensuring consistent relay actuation. One CO (changeover) contact supports flexible control applications, including signal switching and device isolation.
16A switching current and 230V AC switching voltage rating enable connection to powerful loads and motors. Manual operation switch and position indication allow for easy status check and maintenance interventions. Compact dimensions: width 17.5mm, length 58mm, height 89mm, suitable for space-limited setups.
Wide operating temperature range (-20°C to 45°C) provides reliable functionality in harsh environments. Compliant with CE standards, supporting high standards for safety and industrial use.
Applications include industrial automation, signal conditioning, motor control, and equipment protection in manufacturing, process control, and commercial electrical distribution systems. The high thermal current specification (Ith = 16A) and clear switch assignment make it suitable for coupler and interface relay requirements.
Ideal for engineers, panel builders, and maintenance professionals requiring reliable relay performance for DIN rail installations. Use in scenarios such as HVAC control, machinery automation, and system interface circuits.
Explore more Interface Relays and DIN rail industrial automation solutions in EnvMart's Electronics & Electricals category. Discover Dold's trusted range for demanding industrial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay module is rated for a maximum switching current of 16A.
This model operates on a 24V AC coil voltage.
The dimensions of the relay module are 17.5mm in width, 58mm in length, and 89mm in height.
It features a single changeover (CO) contact configuration.
The operating temperature range is from -20°C to 45°C.
Yes, it complies with CE standards for industrial reliability and safety.
It is designed for DIN rail mounting, making installation straightforward.
The relay can handle a maximum switching voltage of 230V AC.
This relay module is suitable for applications such as industrial automation, signal conditioning, motor control, and equipment protection.
Yes, it includes a manual operation switch and clear switch position indication for easy maintenance.
The relay module is manufactured in Germany.
This model belongs to the IK8701 series.
