Wurth Elektronik WR-PHD Series Straight Surface PCB Socket, 24-Contact, 2 Row, 2 mm Pitch, 2A Current, Polyamide 62102421821
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 200V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 2A |
| Mount Type | Surface |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Standards/Approvals | UL Approval E323964, RoHS Approval, REACh Approval Conform or declared, DIN ISO 2768, DIN EN 61760-2 |
| Contact Plating | Gold |
| Number of Contacts | 24 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Offers 24 female contacts in a dual row configuration.
- 2.00 mm pitch ensures precise board-to-board connection.
- Handles a current rating of 2 Amperes and voltage rating of 200 Volts.
- Constructed with polyamide housing featuring gold-plated copper alloy contacts.
- Supports operating temperatures from -40°C to +105°C for reliable performance.
- UL Approved (E323964) and RoHS & REACh compliant for safety and environmental standards.
- Durable design rated for 500 mating cycles ensuring longevity.
- Suitable for electronic component assembly in industrial and manufacturing applications.
Product Description
Wurth Elektronik 62102421821 PCB Socket is a high-quality straight surface mount socket designed with 24 female contacts arranged in 2 rows. This board-to-board connector features a 2 mm pitch, making it suitable for precise printed circuit board applications requiring reliable electrical connections.
The socket is engineered with a polyamide housing that provides robust insulation and mechanical strength, while its contacts are made from copper alloy plated with gold to ensure excellent conductivity and corrosion resistance. Rated for 2A current and 200V voltage, it is ideal for low power electronic applications.
Operating temperature ranges from -40°C to +105°C, enabling use in a variety of environments, including industrial and laboratory settings. The product is UL approved (E323964) and complies with RoHS and REACh regulations, ensuring adherence to global safety and environmental standards.
This socket offers a long lifecycle with a rating of 500 mating cycles, supporting durable and repetitive board connections. Its straight orientation facilitates easy PCB mounting and soldering with a surface mount technique.
24 female contacts in 2 rows for compact board connections. 2 mm pitch ensures compatibility with standard PCB layouts. Gold-plated copper alloy contacts for excellent conductivity and corrosion resistance. Polyamide housing offers mechanical strength and insulation.
Voltage rating of 200V and current rating of 2A for low power applications. Operating temperatures from -40°C to +105°C suitable for diverse environments. UL Approval E323964 certified for safety compliance. RoHS and REACh compliant for environmental safety.
500 mating cycles rating supports repeated use and durability.
This Wurth Elektronik PCB socket is suitable for use in industrial equipment, electronic manufacturing, laboratory instrumentation, and other applications requiring reliable board-to-board connectors. Explore EnvMart's categories for more high-quality electronic components and connectors for your projects.
Explore more products in our PCB Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket has a voltage rating of 200V and a current rating of 2A, making it suitable for low power electronic applications.
It features 24 female contacts arranged in a dual row configuration, allowing for compact board connections.
The contacts in this model are spaced at a 2 mm pitch, ensuring compatibility with standard PCB layouts.
The housing is made of polyamide, while the contacts are composed of gold-plated copper alloy, providing excellent conductivity and corrosion resistance.
This socket operates effectively within a temperature range of -40°C to +105°C, suitable for various environments.
Yes, it is UL approved (E323964) and complies with RoHS and REACh regulations, ensuring adherence to safety and environmental standards.
It is rated for 500 mating cycles, supporting durability and repeated use in applications.
This model uses solder termination, which is suitable for surface mount applications.
The socket has a straight orientation, facilitating easy PCB mounting and soldering.
This socket is designed as a board-to-board connector system, ideal for connecting two printed circuit boards.
The country of origin for this PCB socket is China.
