Wurth Elektronik Brass Screw Terminal Vertical 175A M4 REDCUBE 7461086
Specifications
| Country of Origin | India |
|---|---|
| Screw Size | M4 |
| Brand | Wurth Elektronik |
| Orientation | Vertical |
| Body Material | Brass |
| Current | 175A |
| Model | 7461086 |
| Series | REDCUBE |
| Number of Legs | 12 |
| Number of Rows | 4 |
| Pitch | 2.54mm |
| Body Plating | Tin |
Key Features
- Constructed from brass body material with tin plating for corrosion resistance.
- Features a 2.54mm pitch and 12 legs arranged in 4 rows for secure connections.
- Incorporates press-fit technology for gas-tight and vibration-resistant PCB mounting.
- Enables reliable transfer of high currents up to approximately 300A onto PCBs.
- Eliminates the need for soldering, reducing thermal stress on PCBs.
- Rugged build resists vibration and shock, suitable for industrial environments.
- Applicable in power supplies, converters, battery systems, and automotive industries.
- Easy integration into production processes using simple tooling.
Product Description
Wurth Elektronik 7461086 Brass Screw Terminal Vertical, rated for 175A, is a high-current power element from the REDCUBE series designed for vertical PCB mounting.
Manufactured with a brass body and tin plating, this screw terminal features a 2.54mm pitch and 12 legs arranged in 4 rows, utilizing press-fit technology to provide a gas-tight, vibration-resistant electrical connection to the printed circuit board.
This technology removes the need for soldering, thereby minimizing thermal loads on PCBs and providing high retention forces superior to traditional solder or screw connections. The rugged construction makes it suitable for environments subject to vibration and shock.
The terminal supports current transfers up to approximately 300A, making it ideal for industrial sectors including wind and solar power, medical devices, industrial equipment, agricultural systems, and automotive applications.
Typical uses encompass power supplies, battery systems including emergency power solutions, DC to AC converters, and other high power PCB applications. The snap-in feature simplifies installation and production process integration.
Constructed from brass body with tin plating for durability and corrosion resistance. Press-fit mounting ensures secure, vibration-resistant electrical connections. High current capacity facilitates transfer up to around 300 amperes.
Eliminates soldering, reducing thermal stress during assembly. Rugged design withstands shock and vibration in demanding environments. Effective for a wide range of industrial and commercial sectors. Snap-in design allows for easy mounting and production efficiency.
Employs M4 screw size for reliable mechanical fastening. Features 12 legs distributed in 4 rows for multiple connection points. Pitch of 2.54mm ensures compatibility with standard PCBs.
This Wurth Elektronik brass screw terminal provides a cost-effective, reliable solution for high current PCB connections, enhancing durability and operational safety in electronic assemblies.
Explore more connectors and terminals in the Electronics & Electricals category at EnvMart for complete solutions.
Explore more products in our Screw Terminals category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for 175A, supporting high current applications effectively.
The terminal features a pitch of 2.54mm, ensuring compatibility with standard PCBs.
It has 12 legs arranged in 4 rows for secure connections.
It incorporates press-fit technology for gas-tight and vibration-resistant PCB mounting.
The body is constructed from brass and features tin plating for corrosion resistance.
This terminal employs an M4 screw size for reliable mechanical fastening.
The Wurth Elektronik Brass Screw Terminal is designed for vertical mounting.
This terminal is manufactured in India.
It eliminates the need for soldering, which reduces thermal stress on PCBs.
The rugged build resists vibration and shock, making it suitable for industrial environments.
