KEMET C4C Film Capacitor ±5 % Tolerance 33 nF 3 kV DC 750 V AC Through Hole C4CAYUC2330AA0J

KEMET C4CAYUC2330AA0J is a high-quality film capacitor from the C4C series, designed for through-hole mounting applications. It offers a capacitance of 33 nF with a narrow tolerance of ±5%, capable of handling a rated DC voltage of 3 kV and a rated AC voltage of 750 V. The capacitor features metallised polypropylene film construction which provides excellent self-healing properties and low losses, making it ideal for high-frequency circuits.

These capacitors are widely used in power semiconductor circuits, snubber applications, electronic ballasts, and motor drive circuits where the suppression of voltage peaks and transient voltages is crucial. The product construction includes a plastic case with wire leads and standardized pin spacing for easy PCB mounting.

Key physical dimensions include a body size of 33 mm in length, 20.5 mm in width and height, with a lead length of 6 mm and lead diameter of 1 mm. The capacitor operates reliably across a temperature range from -40°C to 85°C and has an equivalent series resistance (ESR) of 28 mΩ, ensuring efficient performance under ripple current conditions.

Compliance with EN 61071, IEC 61071, and VDE 0560 standards guarantees the capacitor's suitability for industrial and commercial usage. This product is supplied packaged in a bag, ready for insertion into machinery, helping improve production efficiency.

This capacitor has a tolerance of ±5% for precise performance. It features a low dissipation factor of 0.0005% for minimal energy loss. Designed with a plastic package/case and wire terminal type for reliable connections.

Suitable for use in snubber circuits, electronic ballasts, and motor applications. Operating temperature range from -40°C to 85°C ensures durability in various environments. Lead length is 6 mm with a lead diameter of 1 mm for easy PCB insertion.

Complies with EN 61071, IEC 61071, and VDE 0560 standards for industrial quality assurance. Its metallised polypropylene film construction provides self-healing properties and high ripple current capacity.

This KEMET film capacitor is an excellent choice for industrial, manufacturing, laboratory, and electronics repair applications that require reliable snubber and suppression components. For technical designs, 3D models and schematic symbols are available to facilitate PCB integration. Browse a broad selection of Film Capacitors at EnvMart for various electronic component needs.
