Norcomp Micro-D 25 Way Straight Through Hole Female D-Sub Connector 1.27 mm Pitch 500V 1A 380-025-213L001
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500V |
| Brand | Norcomp |
| Orientation | Straight |
| Current | 1A |
| Model | 380-025-213L001 |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | 380 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 25 |
| Contact Gender | Female |
| Connector Gender | Female |
| Connector Type D | Micro-D |
Key Features
- Compact micro-miniature design offers 1/3 the size of standard D-Sub connectors.
- Metal-to-metal interface enhances grounding and shielding performance.
- Solder termination type ensures secure contact connections.
- Rated for 1 Amp current and 500 Volt voltage for reliable performance.
- Female connector gender suitable for receiving male connector pins.
- Operating temperature range from -55°C to 85°C for versatile environmental application.
- Constructed with polybutylene terephthalate housing for durability and insulation.
- Gold-plated brass contacts provide excellent conductivity and corrosion resistance.
Product Description
Norcomp 380-025-213L001 micro-D 25 way straight through hole female D-Sub connector features a compact 1.27 mm pitch design suitable for PCB mounting. This connector offers robust mechanical connection and excellent electrical performance with a 1 Amp current rating and 500 Volt voltage handling.
The micro-miniature D-Sub connector is significantly smaller than standard connectors, occupying only one-third of their space, making it ideal for applications where real estate is critical. Its metal-to-metal interface enhances grounding and shielding to reduce electromagnetic interference and improve signal integrity.
Featuring a polybutylene terephthalate housing and gold-plated brass contacts, it is built for durability and reliability. The solder termination type and through hole mount type facilitate a strong, permanent PCB connection. This connector operates reliably in temperatures ranging from -55°C to 85°C, suitable for varied industrial environments.
Compact 1/3 size of standard D-Sub connectors reduces PCB space requirements. Metal-to-metal interface provides improved grounding and shielding. Solder termination ensures robust electrical connection. 1 Amp and 500 Volt rating enable use in demanding electronic applications.
Gold-plated brass contacts enhance conductivity and corrosion resistance. Operating temperature range from -55°C to 85°C supports diverse environmental conditions. Through hole mounting type offers reliable PCB mechanical retention.
Polybutylene terephthalate housing offers excellent insulation and durability. Female micro-D connector designed to intermate with commercial micro-D connectors. Ideal for commercial electronics, power connectors, and industrial control systems.
This high-quality Norcomp micro-D connector series meets the needs of electronics and power connector applications in commercial, industrial, and manufacturing sectors, providing dependable and compact interconnect solutions. Explore more D-Sub Connectors from Norcomp and enhance your electronic designs with trusted quality components available at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 1 Amp and a voltage of 500 Volts, making it suitable for various electronic applications.
It operates reliably within a temperature range of -55°C to 85°C, allowing for versatility in different environmental conditions.
This unit features a solder termination type, ensuring a secure and permanent connection when mounted on a PCB.
The connector has a pitch size of 1.27 mm, which is compact and suitable for space-constrained applications.
It is constructed with a polybutylene terephthalate housing and features gold-plated brass contacts for enhanced conductivity and corrosion resistance.
This model has 25 contacts, designed for reliable electrical connections in various applications.
It features a through hole mounting type, which provides reliable mechanical retention on printed circuit boards.
This is a female connector, designed to receive male connector pins for interconnection.
The connector is manufactured in Taiwan, ensuring adherence to quality standards.
It is ideal for commercial electronics, power connectors, and industrial control systems, providing compact interconnect solutions.
The orientation of this model is straight, facilitating easy alignment and installation in various setups.
The metal-to-metal interface enhances grounding and shielding performance, reducing electromagnetic interference and improving signal integrity.
