KEMET C4C Film Capacitor ±5% 22 nF 3 kV DC 750 V AC Through Hole Mount C4CAYUC2220AA0J
Specifications
| Country of Origin | India |
|---|---|
| Brand | KEMET |
| Height | 17mm |
| Length | 33mm |
| Model | C4CAYUC2220AA0J |
| Packaging | Bag |
| Width | 17mm |
| Mount Type | Through Hole |
| Series | C4C |
| Maximum Operating Temperature | 85°C |
| Tolerance | ±5 % |
| Capacitance | 22nF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Wire |
| Dissipation Factor | 0.0005% |
| Lead Length | 6mm |
| Standards/Approvals | EN 61071, IEC 61071, VDE 0560 |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 750V ac |
| Rated DC Voltage | 3kV dc |
| Lead Diameter | 1mm |
| Equivalent Series Resistance ESR | 42mΩ |
Key Features
- Capacitance of 22 nF with a tolerance of ±5%.
- Rated for 3 kV DC and 750 V AC voltages.
- Through hole mount type suitable for reliable PCB insertion.
- Plastic package/case with wire terminal type and 6 mm lead length.
- Operates in temperatures ranging from -40°C to 85°C.
- Low equivalent series resistance of 42 mΩ ensuring efficient performance.
- Complies with EN 61071, IEC 61071, and VDE 0560 standards.
Product Description
The KEMET C4CAYUC2220AA0J is a high-performance polypropylene film capacitor suitable for demanding industrial and electronic applications. With a capacitance value of 22 nF and tight tolerance of ±5%, this capacitor ensures reliable operation under high voltage conditions.
This film capacitor is rated for 3 kV DC and 750 V AC, making it ideal for power semiconductor circuits where suppression of voltage peaks is critical. It features a through-hole mount design for easy PCB assembly and is housed in a robust plastic case with wire terminals and a lead length of 6 mm.
The capacitor is designed to operate effectively over a wide temperature range from -40°C to 85°C and exhibits a very low equivalent series resistance (ESR) of 42 mΩ, which reduces power loss and improves performance in high-frequency environments.
Compliance with international standards such as EN 61071, IEC 61071, and VDE 0560 guarantees quality and safety for various industrial, laboratory, and manufacturing use cases including electronic ballasts, motor control circuits, and snubber applications.
This component's physical dimensions (33 mm length, 17 mm width, and 17 mm height) along with a lead diameter of 1 mm ensure compatibility with common industrial assembly processes.
Capacitance of 22 nF with ±5% tolerance. Rated AC voltage of 750 V and DC voltage of 3 kV. Through hole mount type with wire terminals. Low ESR of 42 mΩ supports high-frequency applications. Compliance with EN 61071, IEC 61071, and VDE 0560 standards.
Operating temperature from -40°C to 85°C. Plastic package ensuring durability and electrical insulation. Dimensions: 33x17x17 mm with 6 mm lead length and 1 mm lead diameter.
This capacitor is well suited for industrial electronics, HVAC systems, power supplies, motor drives, and other commercial applications requiring stable and reliable film capacitors. Browse the Electronics Components and Film Capacitor category on EnvMart to explore more options from KEMET and other top brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this model is 22 nF with a tolerance of ±5%.
It is rated for 3 kV DC and 750 V AC, making it suitable for high voltage applications.
The equivalent series resistance (ESR) of this capacitor is 42 mΩ, which supports efficient performance in high-frequency applications.
This capacitor operates effectively over a temperature range from -40°C to 85°C.
It features a through-hole mount design, suitable for reliable PCB insertion.
The physical dimensions are 33 mm in length, 17 mm in width, and 17 mm in height.
It has wire terminals with a lead length of 6 mm and a lead diameter of 1 mm.
This model complies with EN 61071, IEC 61071, and VDE 0560 standards.
The capacitor is packaged in a bag for convenient handling and storage.
It is well suited for industrial electronics, HVAC systems, power supplies, and motor drives.
This capacitor belongs to the C4C series, which is known for its high-performance polypropylene film capacitors.
The dissipation factor for this capacitor is 0.0005%, indicating low energy loss during operation.
