TDK HighE Series Metal Oxide Varistor 1.9 nF Capacitance 300 A Clamping Current 1025 V Clamping Voltage B72240B0381K001
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 40mm |
| Brand | TDK |
| Material | Metal |
| THICKNESS | 14mm |
| Length | 60mm |
| Model | B72240B0381K001 |
| Depth | 14mm |
| Series | HighE |
| Energy Rating | 800J |
| Maximum Operating Temperature | 85°C |
| Capacitance | 1.9nF |
| Minimum Operating Temperature | -40°C |
| Maximum dc Voltage | 505V dc |
| Standards/Approvals | CSA, UL |
| Pin Count | 2 |
| Termination Style | Screw |
| Lead Pitch | 24mm |
| Maximum AC Voltage | 385V ac |
| Clamping Voltage VC | 1025V |
| Clamping Current | 300A |
| Maximum Surge Current | 40kA |
| Varistor Voltage | 620 V |
Key Features
- Constructed with metal oxide material for durability and high performance.
- Designed for heavy-duty surge current capability up to 40 kA.
- Features a clamping voltage of 1025 V and varistor voltage of 620 V.
- Encapsulated in flame-retardant plastic housing to UL 94 V-0 standards.
- Equipped with M4 and M5 screw connectors for secure termination.
- Operating temperature range from -40°C to 85°C to suit varied environments.
- Energy rating of 800 J suitable for industrial and electronic surge protection.
- Diameter of 40 mm with 60 mm length and 14 mm thickness for compact design.
Product Description
TDK B72240B0381K001 HighE Series Metal Oxide Varistor provides reliable surge protection with a capacitance of 1.9 nF, a clamping current of 300 A, and a clamping voltage of 1025 V. This varistor is designed for use in industrial, electronic, and power supply applications where robust protection against voltage surges is essential.
Manufactured with a metal oxide composition, the device supports a maximum surge current of 40 kA and features a varistor voltage rating of 620 V. The spherical varistor measures 40 mm in diameter, 60 mm in length, and 14 mm in thickness, making it suitable for compact enclosure installation.
The unit is housed in a flame-retardant plastic casing conforming to UL 94 V-0 standards, providing additional safety. It includes M4 and M5 screw connectors for stable and secure fastening. Operating temperatures range from a minimum of -40°C to a maximum of 85°C, allowing it to perform reliably under varied environmental conditions.
This varistor series complies with UL and CSA certifications, underscoring its quality and safety in surge protection systems. Its energy rating of 800 J equips it to absorb transient energy events without damage, making it ideal for use in industrial equipment, power supplies, household electronics, and laboratory instruments.
Constructed with metal oxide for enhanced surge durability. High clamping current of 300 A suited for heavy-duty applications. Compact disk shape with precise dimensions for easy integration. Termination style includes screw connectors for reliable contacts.
Flame-retardant housing enhances safety in demanding environments. Wide operating temperature range from -40°C to 85°C. Compliance with UL and CSA standards. Lead pitch optimized for installation convenience. Energy rating of 800 J to protect against high-energy surges.
Ideal for electronic components, power supplies, and industrial machines. Explore the comprehensive range of Varistors and surge protection components by TDK on EnvMart to enhance your electronic system reliability.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The clamping voltage of this model is 1025 V.
It can handle a maximum surge current of 40 kA.
The capacitance of this unit is 1.9 nF.
The varistor has a diameter of 40 mm, a length of 60 mm, and a thickness of 14 mm.
It has an energy rating of 800 J, suitable for absorbing transient energy events.
The operating temperature range is from -40°C to 85°C.
It features screw termination style with M4 and M5 connectors for secure fastening.
This varistor complies with UL and CSA standards, ensuring safety and quality.
The varistor voltage rating is 620 V.
The country of origin for this varistor is India.
It is constructed with metal oxide material for enhanced surge durability.
It is suitable for industrial equipment, power supplies, household electronics, and laboratory instruments.
