TDK Standard Metal Oxide Varistor 5.2 nF Capacitance 5 A Clamping Voltage 43 V Model B72210S0140K101

Free Delivery in India | Lowest Global Shipping Charges

TDK Standard Metal Oxide Varistor 5.2 nF Capacitance 5 A Clamping Voltage 43 V Model B72210S0140K101



Category Varistor Brand TDK Condition New

Specifications

Country of Origin	India
Diameter	12mm
Brand	TDK
Material	Metal
THICKNESS	4.2mm
Length	14.5mm
Model	B72210S0140K101
Packaging	Bulk
Series	Standard
Energy Rating	2J
Maximum Operating Temperature	85°C
Capacitance	5.2nF
Minimum Operating Temperature	-40°C
Maximum dc Voltage	18V dc
Standards/Approvals	VDE, UL, EC, CSA, CQC
Pin Count	2
Termination Style	Solder
Lead Pitch	7.5mm
Maximum AC Voltage	14V ac
Clamping Voltage VC	43V
Clamping Current	5A
Maximum Surge Current	500A
Varistor Voltage	22 V

Key Features

Bulk packaged metal oxide varistor designed for high surge current tolerance.
Rated clamping voltage of 43 V and varistor voltage of 22 V for effective voltage suppression.
Compact ceramic body with epoxy resin coating and solder termination style.
Operating temperature range from -40°C to 85°C suitable for varied environments.
Maximum AC and DC voltages of 14 V AC and 18 V DC respectively.
Energy rating of 2 Joules capable of dissipating transient energy safely.
Tinned copper leads with 7.5 mm lead pitch facilitate easy PCB mounting.
Complies with multiple international approvals including VDE, UL, EC, CSA, and CQC.

Product Description

TDK B72210S0140K101 Standard Metal Oxide Varistor offers reliable surge protection with capacitance of 5.2 nF and a clamping current rating of 5 A. This component is engineered with a ceramic body coated in epoxy resin, ensuring durability and stability in industrial and electronics applications.

With a clamping voltage of 43 V and varistor voltage of 22 V, it effectively limits voltage spikes to protect connected circuits. Designed for a broad operating temperature from -40°C up to 85°C, it is suitable for diverse operating environments.

The varistor supports a maximum AC voltage of 14 V and maximum DC voltage of 18 V, complying with critical surge withstand demands. It has an energy rating of 2 Joules, making it capable of safely dissipating transient energy generated by surges and spikes.

Its physical dimensions include a diameter of 12 mm, length of 14.5 mm, and thickness of 4.2 mm, allowing for compact placement on circuit boards. The device features tinned copper wire leads with 7.5 mm lead pitch for easy solder termination and assembly.

Certified under recognized standards such as VDE, UL, EC, CSA, and CQC, the varistor meets stringent quality and safety benchmarks. It is ideal for use in industrial, electronics manufacturing, power supply, and surge protection systems.

Bulk packaged metal oxide varistor designed for high surge current tolerance. Rated clamping voltage of 43 V and varistor voltage of 22 V for effective voltage suppression. Compact ceramic body with epoxy resin coating and solder termination style.

Operating temperature range from -40°C to 85°C suitable for varied environments. Maximum AC and DC voltages of 14 V AC and 18 V DC respectively. Energy rating of 2 Joules capable of dissipating transient energy safely. Tinned copper leads with 7.5 mm lead pitch facilitate easy PCB mounting.

Complies with multiple international approvals including VDE, UL, EC, CSA, and CQC. Diameter of 12 mm, thickness 4.2 mm and length 14.5 mm for compact installations.

This varistor is highly suitable for protecting sensitive electronics in industrial, power supply, telecommunications, and consumer electronics sectors. It provides dependable protection against voltage surges and transients.
