| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Model | PDTC124XQB-QZ |
| Mount Type | Surface |
| Series | PDTC124X |
| Maximum Operating Temperature | 150°C |
| Package Type | DFN1110D-3 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Collector Emitter Voltage Vceo | 50V |
| Minimum DC Current Gain hFE | 60 |
| Transistor Polarity | NPN |
| Maximum Emitter Base Voltage VEBO | 10V |
| Maximum Collector Base Voltage VCBO | 50V |
| Automotive Standard | AEC-Q101 |
| Maximum DC Collector Current Idc | 100mA |
| Transistor Configuration | NPN |
| Maximum Transition Frequency ft | 230MHz |
Nexperia PDTC124XQB-QZ resistor-equipped transistor is a high-performance NPN transistor designed for surface mount applications, housed in an ultra-small DFN1110D-3 leadless plastic package with side-wettable flanks. This transistor achieves a maximum DC collector current of 100 mA and withstands voltages up to 50 V collector-emitter, suitable for digital switching and control circuits.
The built-in resistors integrated within the device simplify circuit design by reducing the need for external components, thus lowering assembly complexity and component count. Its low package height of just 0.5 mm makes it ideal for compact PCB designs where space is constrained.
Featuring a maximum transition frequency of 230 MHz, this transistor is capable of handling fast-switching signals, making it viable for various digital applications. The device supports an operating temperature range from -55°C up to 150°C, ensuring reliability in harsh thermal environments.
Compliance with RoHS and automotive standard AEC-Q101 underscores its suitability for automotive and industrial use cases. The transistor’s surface mount design is compatible with automated optical inspection (AOI) methods for quality solder joint verification.
Integrated resistors simplify circuit design and reduce component count. Compact DFN1110D-3 package with side-wettable flanks enhances PCB mounting reliability. 100 mA collector current and 50 V collector-emitter voltage specifications.
High transition frequency of 230 MHz supports digital switching. Operation temperature range from -55°C to 150°C for versatile applications. Meets RoHS and automotive AEC-Q101 standards. Low-profile 0.5 mm package height saves PCB space.
Compatible with AOI for solder joint inspection.
This transistor is ideal for use in digital input controlling ICs, load switching, and various industrial, automotive, and electronic manufacturing applications requiring compact, reliable discrete semiconductor components.
