Nexperia Resistor-Equipped PNP Transistor PDTA123JQC-QZ, -100 mA, -50 V, 3-Pin DFN1412D-3
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Model | PDTA123JQC-QZ |
| Mount Type | Surface |
| Series | PDTA123J |
| Maximum Operating Temperature | 150°C |
| Package Type | DFN1412D-3 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Collector Emitter Voltage Vceo | -50V |
| Transistor Polarity | PNP |
| Maximum Emitter Base Voltage VEBO | -10V |
| Automotive Standard | AEC-Q101 |
| Maximum DC Collector Current Idc | -100mA |
| Transistor Configuration | PNP |
Key Features
- Equipped with built-in resistors for simplified circuit design.
- Supports maximum emitter base voltage of -10 V.
- Operating temperature range from -55°C to 150°C ensures reliability.
- Surface mount device with ultra small plastic package and side-wettable flanks.
- Complies with RoHS standards and automotive AEC-Q101 qualification.
- Suitable for digital applications as a cost-saving alternative to BC857 series.
- Low package height of 0.5 mm supports automated optical inspection.
- Ideal for controlling IC inputs and switching loads.
Product Description
The Nexperia PDTA123JQC-QZ is a resistor-equipped PNP transistor designed for efficient surface mount applications, featuring an ultra compact 3-pin DFN1412D-3 plastic package with side-wettable flanks for reliable soldering and inspection. It can handle a maximum DC collector current of -100 mA and a maximum collector emitter voltage of -50 V, supporting a maximum emitter base voltage of -10 V, making it a robust choice for various digital switching and control circuit applications.
Operating reliably over a wide temperature range from -55°C to 150°C, this transistor meets strict RoHS compliance and the automotive standard AEC-Q101, ensuring high quality and environmental safety. The integrated resistors significantly simplify circuit design by reducing the need for additional external components, thus lowering production costs and assembly complexity.
Its low profile package height of 0.5 mm is optimized for automated optical inspection (AOI), making it suitable for high volume manufacturing. The PDTA123JQC-QZ offers a versatile and cost-effective replacement for the BC857 series in digital applications, including controlling IC inputs and load switching tasks where compact and reliable transistors are required.
Nexperia's transistor series PDTA123J enhances designs by reducing component counts, improving reliability, and aiding efficient mass production processes. Equipped with built-in resistors reducing component count. Supports automatic optical inspection with low package height.
Compliant with RoHS and automotive AEC-Q101 standards. Wide operating temperature range from -55°C to 150°C. Surface mount 3-pin DFN1412D-3 package with side-wettable flanks. Suitable for digital switching and controlling inputs on ICs.
Cost-saving alternative to BC857 transistor series. Reliable operation with -100 mA current capacity and -50 V voltage rating. Explore the full range of Bipolar Transistors at EnvMart for industrial, automotive, and electronic circuit design applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum collector emitter voltage (Vceo) for this model is -50 V.
It can handle a maximum DC collector current of -100 mA.
The operating temperature range is from -55°C to 150°C.
This model uses a 3-pin DFN1412D-3 surface mount package with side-wettable flanks.
It complies with RoHS standards and the automotive AEC-Q101 qualification.
The maximum emitter base voltage (VEBO) is -10 V.
This model is a PNP transistor configuration.
It has a pin count of 3.
The built-in resistors simplify circuit design by reducing the need for additional external components.
It is suitable for digital switching and controlling inputs on ICs, serving as a cost-saving alternative to the BC857 series.
The country of origin for the PDTA123JQC-QZ is India.
The low profile package height of 0.5 mm supports automated optical inspection, making it suitable for high volume manufacturing.
