TE Connectivity PIDG Insulated Ring Terminal M5 Stud Size 22 AWG to 16 AWG Wire Size Red 130005

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity PIDG Insulated Ring Terminal M5 Stud Size 22 AWG to 16 AWG Wire Size Red 130005

Name: TE Connectivity PIDG Insulated Ring Terminal M5 Stud Size 22 AWG to 16 AWG Wire Size Red 130005
Brand: TE Connectivity
SKU: 177791
Price: 0.78 USD
Availability: InStock



Category Ring Terminal Brand TE Connectivity Condition New

Specifications

Country of Origin	United States
Brand	TE Connectivity
Colour	Red
THICKNESS	0.79mm
Model	130005
Insulation	Insulated
Overall Length	21.6mm
Contact Material	Copper
Series	PIDG
Maximum Operating Temperature	105°C
Insulation Material	Nylon
Standards/Approvals	RoHS
Contact Plating	Tin
Minimum Wire Size AWG	22AWG
Maximum Wire Size AWG	16AWG
Outer Ring Diameter	7.92mm
Inner Ring Diameter	5mm
Stud Size	M5

Key Features

The ring terminal is insulated with durable nylon material providing electrical insulation and mechanical protection.
Suitable for wire sizes from 22 AWG minimum to 16 AWG maximum.
The M5 stud size and tin-plated copper contact ensure reliable electrical connectivity and corrosion resistance.
Overall length of the terminal is 21.6 mm with an outer ring diameter of 7.92 mm and inner diameter of 5 mm matching the M5 stud size.
Designed to operate at temperatures up to 105°C making it ideal for various electrical applications.
Red colour insulation facilitates wire identification and size coding per industry standards.
Complies with RoHS environmental standards for restricted hazardous substances.
Manufactured in the United States ensuring quality and reliability.

Product Description

TE Connectivity presents the 130005 PIDG Insulated Ring Terminal with a stud size of M5 and wire size range from 22 AWG to 16 AWG, insulated in red nylon. This ring terminal features a flat ring with a central hole designed to connect firmly to an M5 stud or bolt, while the barrel end is a hollow tube for crimping stranded wires, ensuring secure and reliable electrical connections.

The contact material is high-quality copper plated with tin for enhanced corrosion resistance and conductivity. The nylon insulation provides robust protection against mechanical wear and electrical shorts while also offering colour coding for easy wire size identification.

With an overall length of 21.6 mm, outer ring diameter of 7.92 mm, and inner ring diameter matching the M5 stud size at 5 mm, this ring terminal fits standard bus bars, connectors, and screw terminals. The thickness of 0.79 mm balances mechanical strength with ease of crimping.

Designed for use in industrial and commercial electrical wiring tasks, this ring terminal is suitable for applications requiring secure and standardized wire terminations, including control panels, machinery wiring, and electrical assemblies.

Durable nylon insulation provides electrical and mechanical protection. Copper contact with tin plating ensures conductivity and corrosion resistance. Compatible with wire sizes ranging from 22 AWG to 16 AWG. Fits M5 stud size with precise ring dimensions for secure connections.

Operates at maximum temperatures up to 105°C. Red insulation allows easy identification and wiring standards compliance. RoHS compliant for environmental safety. Manufactured in the United States maintaining high-quality standards.

This Ring Terminal is an essential component for electrical technicians, engineers, and assemblers involved in wiring and terminating electrical circuits in industrial, commercial, and vehicular systems.

Explore more reliable electrical connectors and wire terminals in the Wire Terminals & Splices category on EnvMart to meet your technical requirements.
