Samtec TSM Series Vertical Surface Pin Header, 2 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSM-102-01-L-SH-A-K-TR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 5.4A |
| Model | TSM-102-01-L-SH-A-K-TR |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
Key Features
- Constructed with a liquid crystal polymer housing providing durability and stability.
- Phosphor bronze contacts plated with gold ensure reliable conductivity and corrosion resistance.
- Rated for 5.4A current and 475V maximum voltage for robust electrical performance.
- Designed for vertical board-to-board connector system with surface mount termination.
- Operates efficiently across a wide temperature range from -55°C to 125°C.
- Contact gender is male with solder termination type for easy PCB assembly.
- Comes in tape and reel packaging facilitating automated pick & place processes.
- Includes polyimide film pick & place pad and is a single horizontal row connector.
Product Description
Samtec brand TSM-102-01-L-SH-A-K-TR model vertical surface pin header features 2 contacts with a 2.54 mm pitch in an unshrouded, single-row configuration for precise board-to-board connections. This surface mount technology (SMT) component is designed with a liquid crystal polymer housing for excellent mechanical strength and insulating properties, ideal for industrial and electronic assembly applications.
The pin header uses phosphor bronze contacts with a light selective gold plating (.000254 mm) in the contact area, ensuring high reliability and corrosion resistance. This model is rated for an operating current of 5.4A and a voltage of up to 475V, suitable for demanding electrical applications. It supports a wide operating temperature range from -55°C to 125°C, making it adaptable to harsh environments.
Its vertical orientation and unshrouded design facilitate easy mating and integration with compatible connectors. The termination is through soldering, which is the standard for PCB mounting, ensuring strong and conductive attachment. Packing comes in tape and reel format, optimized for automated pick and place manufacturing processes.
This header is applicable in industrial electronics manufacturing, automation, telecommunications, and other sectors requiring dependable PCB connector solutions. It supports single horizontal row alignment pins and includes a polyimide film pick & place pad for precise placement.
Liquid crystal polymer housing for durability and insulation. Phosphor bronze contacts with selective gold plating for conductivity. Rated 5.4A current and 475V voltage for robust use. Single row, vertical, unshrouded design for ease of installation.
Tape and reel packaging for manufacturing automation. Wide operating temperature range of -55°C to 125°C. Male contact gender and solder termination type.
Samtec PCB headers are widely used in electronics manufacturing and industrial assembly, offering high performance and reliability. Explore more in the PCB Headers category on EnvMart for compatible connectors and accessories.
