Samtec SSM Series Vertical Surface PCB Socket 10-Contact 1 Row 2.54 mm Pitch Solder SSM-105-L-SV-P-TR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 572V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 5.2A |
| Model | SSM-105-L-SV-P-TR |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | SSM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | PCB Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Constructed with phosphor bronze contacts plated with gold for excellent conductivity and corrosion resistance.
- Housing made from liquid crystal polymer for high durability and thermal stability.
- Designed for vertical board-to-board connector systems with surface mount technology.
- Supports operating voltage up to 572 V and current capacity of 5.2 A.
- Operates reliably in temperature ranges from -55°C to 125°C.
- Packaged in tape and reel format suitable for automated assembly.
- Includes a plastic pick and place pad for precise SMT placement.
- Suitable for industrial electronics applications including PCB connectors and wire housings.
Product Description
Samtec SSM-105-L-SV-P-TR is a high-quality vertical surface mount PCB socket designed for board-to-board connection solutions in electronic assemblies. Featuring 10 female contacts arranged in a single row with a precise 2.54 mm pitch, this socket provides reliable electrical connections with solder termination.
The contact material is phosphor bronze plated with 0.000254 mm gold, ensuring excellent conductivity and corrosion resistance for long-term durability. The housing is constructed from liquid crystal polymer, offering robust mechanical strength and thermal stability suitable for harsh industrial environments.
This PCB socket supports a maximum operating voltage of 572 volts and current up to 5.2 amps, making it ideal for demanding electronics applications. It is rated for use within a temperature range of -55°C to 125°C, accommodating various operational conditions.
Designed for vertical orientation and surface mounting, the SSM series socket includes a plastic pick and place pad that facilitates automated SMT processing. It is supplied in tape and reel packaging to streamline assembly line efficiency.
This model belongs to Samtec's SSM series, recognized for its tiger claw SMT design with 5 pins per row to maximize connection integrity. Its compact and robust form factor suits applications in industrial control, telecommunications, and consumer electronics requiring durable board-to-board connectors.
Constructed with phosphor bronze gold-plated contacts for superior conductivity. Liquid crystal polymer housing offers mechanical robustness. Supports 572 V voltage and 5.2 A current rating. Operates across a wide temperature range from -55°C to 125°C.
Designed for vertical surface mount technology and automated assembly. Packaged in tape and reel format for manufacturing convenience. Enables reliable board-to-board connections in PCB applications.
Explore more industrial electronic components and PCB Sockets at EnvMart to find the best solutions for your application needs. Samtec SSM series offers dependable connectors engineered for precision and durability.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating voltage for this model is 572 volts.
This PCB socket can handle a current capacity of 5.2 amps.
The contacts in this socket are arranged with a pitch of 2.54 mm.
The contacts are made of phosphor bronze and are gold plated, while the housing is constructed from liquid crystal polymer.
It operates reliably in temperature ranges from -55°C to 125°C.
This model features 10 female contacts arranged in a single row.
Yes, this PCB socket is designed for surface mount technology.
The SSM-105-L-SV-P-TR uses solder termination for its connections.
This model is designed for vertical orientation.
It is packaged in tape and reel format, suitable for automated assembly.
This PCB socket is suitable for industrial electronics applications including PCB connectors and wire housings.
The country of origin for this model is India.
