Molex Sabre Series Right Angle Through Hole PCB Header, 6 Contacts, 7.5 mm Pitch, 1 Row, Shrouded, 600V, 18A 43160-3106
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 18A |
| Mount Type | Through Hole |
| Contact Material | Brass |
| Series | Sabre |
| Termination Type | Solder |
| Maximum Operating Temperature | 75°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 7.5mm |
| Contact Plating | Tin |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.81mm |
Key Features
- This PCB header operates at a voltage of 600 volts.
- Supports a current rating of 18 amperes for high current applications.
- Features a right-angle orientation with shrouded design for secure connections.
- Constructed with brass contacts plated with tin for durability.
- Designed with a 3.81 mm tail pin length for solder termination.
- Operates reliably in temperatures ranging from -40°C to 75°C.
- Offers positive locking casings to prevent accidental disconnection.
- Casings are polarized to ensure correct mating and orientation.
Product Description
Molex 43160-3106 Sabre Series Right Angle Through Hole PCB Header features 6 male contacts arranged in a single row with 7.5 mm pitch. It is designed for wire-to-board connections requiring a robust and reliable interface for electronic assembly.
This connector supports up to 18A current and 600V voltage, suitable for high current applications in industrial and electronic equipment. The Brass contacts with tin plating ensure good electrical conductivity and corrosion resistance.
The header is right-angle oriented with shrouded casing to protect contacts and enhance secure mating. The 3.81 mm tail pin length is optimized for soldering onto PCBs.
Operating temperature range is from -40°C to 75°C allowing uses in diverse environments. The casing includes positive locking mechanisms with audible clicks that prevent accidental disconnection during service or operation. Polarized casings ensure correct mating alignment.
This product is ideal for use in industrial automation, communication devices, power supply units, and other electronic manufacturing where durable, high-performance PCB connections are required.
This PCB header operates at a voltage of 600 volts. Supports a current rating of 18 amperes for high current applications. Features a right-angle orientation with shrouded design for secure connections. Constructed with brass contacts plated with tin for durability.
Designed with a 3.81 mm tail pin length for solder termination. Operates reliably in temperatures ranging from -40°C to 75°C. Offers positive locking casings to prevent accidental disconnection. Casings are polarized to ensure correct mating and orientation.
Suitable for single-row mounting with through hole installation. Complies with UL E29179 and UL1950 standards, though no additional certifications are provided. Set a standard for quality and durability in PCB connector solutions with the Molex Sabre Series.
Explore more in the PCB Headers category at EnvMart for compatible and complementary electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header operates at a maximum voltage of 600 volts.
It supports a current rating of 18 amperes, making it suitable for high current applications.
The contacts are arranged with a pitch of 7.5 mm.
This model features a solder termination type for secure connections.
The tail pin length is designed at 3.81 mm.
It operates reliably in temperatures ranging from -40°C to 75°C.
This model features 6 male contacts arranged in a single row.
The contacts are constructed from brass and plated with tin for improved conductivity and corrosion resistance.
It includes positive locking casings that prevent accidental disconnection during operation.
Yes, the casings are polarized to ensure correct mating and orientation.
This model is designed for through hole mounting.
It complies with UL E29179 and UL1950 standards.
