Molex Sabre Series Straight Through Hole PCB Header, 2 Contacts, 7.49 mm Pitch, 1 Row, Shrouded, 600V, 18A 43160-2102

Molex 43160-2102 Sabre Series PCB Header is a shrouded straight through hole connector designed to provide robust and reliable wire-to-board connections. It features 2 male contacts with a pitch of 7.49 mm and is built to support currents up to 18 amperes at a voltage rating of 600 volts. The single row, shrouded design offers enhanced connector locking with a positive audible click, preventing accidental disconnection.

The housing is made from high temperature thermoplastic, enhancing durability in demanding industrial environments. The brass contacts plated with tin ensure consistent electrical conductivity and corrosion resistance. Its operating temperature range from -40°C to 75°C makes it suitable for a wide range of applications.

This connector is ideal for use in electronic circuits, PCB assemblies, industrial power systems, and various commercial electronics requiring robust and secure connections. The through hole mount provides mechanical stability on PCBs, and the 3.81 mm tail pin length allows efficient solder termination. The connector system is wire-to-board and designed with harpoons to secure the connector firmly on the PCB.

Supports a current rating of up to 18 amperes for high power applications. Features a sturdy high temperature thermoplastic housing for durability. Includes male brass contacts plated with tin for reliable conductivity. Designed with a single row configuration and 7.5 mm row pitch for compact PCB layouts.

Shrouded casing ensures positive locking with an audible click to prevent accidental disconnection. Operating temperature range from -40°C to 75°C allowing use in varied environments. Through hole mount type ensures secure PCB attachment and mechanical stability.

Offers a tail pin length of 3.81 mm for effective solder termination. Ideal for industrial electronic equipment, power connectors, and other PCB applications.

Standards and approvals for this product are not specified. The Molex Sabre Series is widely respected for its reliable performance in power and signal transmission within various electrical and electronic industrial applications. For further design integration, 3D models and technical documentation are available, supporting efficient engineering and production processes.
