Samtec CLM Series Straight Surface PCB Socket, 8-Contact, 2 Row, 1 mm Pitch, 3.1A Current, 270V Voltage CLM-104-02-L-D-TR

Name: Samtec CLM Series Straight Surface PCB Socket, 8-Contact, 2 Row, 1 mm Pitch, 3.1A Current, 270V Voltage CLM-104-02-L-D-TR
Brand: Samtec
SKU: 166445
Price: 2.88 USD
Availability: InStock



Category PCB Sockets Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	270V
Brand	Samtec
Orientation	Straight
Current	3.1A
Model	CLM-104-02-L-D-TR
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	CLM
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Socket
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	1mm
Contact Plating	Gold
Number of Contacts	8
Connector System	Board-to-Board

Key Features

Designed for surface mount technology with straight orientation.
Constructed using durable Liquid Crystal Polymer housing.
Gold-plated phosphor bronze contacts ensure reliable conductivity.
Supports a maximum current of 3.1A and voltage rating of 270V.
Operates reliably between -55°C and 125°C temperature range.
Includes low profile dual wipe Tiger Claw™ contact for improved signal integrity.
Ideal for compact electronic applications requiring robust PCB connectivity.
Available with optional tape and reel packaging for automated assembly.

Product Description

Samtec CLM-104-02-L-D-TR is a high-quality straight surface mount PCB socket designed for board-to-board connector systems featuring 8 contacts in 2 rows with a 1 mm pitch. Manufactured with precision engineering, this component incorporates a Liquid Crystal Polymer housing which provides excellent durability and heat resistance, enabling reliable performance in demanding industrial and electronic applications.

The socket's phosphor bronze contacts are gold-plated to ensure minimal contact resistance and long-term corrosion resistance. Its low profile dual wipe Tiger Claw™ contact design enhances signal integrity and mechanical retention, making it suitable for applications requiring consistent electrical performance.

Rated for 3.1 amps current and 270 volts, it operates safely across a wide temperature range from -55°C to 125°C. This specification makes it well-suited for use in industrial electronics, consumer devices, communication equipment, and other applications where compact and reliable PCB interconnections are essential.

Mount type is surface mount with a straight orientation to facilitate efficient PCB layout. The socket is part of the CLM series by Samtec and can be ordered with optional tape and reel packaging to support automated manufacturing processes.

Designed for surface mount technology with straight orientation. Constructed using durable Liquid Crystal Polymer housing. Gold-plated phosphor bronze contacts ensure reliable conductivity. Supports a maximum current of 3.1A and voltage rating of 270V.

Operates reliably between -55°C and 125°C temperature range. Includes low profile dual wipe Tiger Claw™ contact for improved signal integrity. Ideal for compact electronic applications requiring robust PCB connectivity. Available with optional tape and reel packaging for automated assembly.

This PCB socket is ideal for industrial, laboratory, manufacturing, and electronic assembly applications requiring high-quality, durable PCB connectors to ensure reliable electrical connections.
