Cosel High Efficiency PCB Mount DC/DC Converter 5V DC 3A Output, 9-12V Input, 15W Max Power, 6-Pin DIP Package MGS151205-R

Cosel MGS151205-R DC/DC Converter is a high quality PCB mounted power supply module designed to convert input voltages from 9V to 12V DC reliably into a stable 5V DC output at a current capacity of up to 3 A and maximum power output of 15 W. This efficient device achieves an operating efficiency of approximately 87%, utilizing a synchronised rectification circuit to minimize energy loss and heat generation.

Its compact dual in-line package (6-pin DIP) with dimensions of 25.4mm in length, 9.9mm width, and 9.9mm depth allows seamless integration into printed circuit boards. The unit incorporates a high isolation voltage capacity of 1.5 kV AC to enhance safety in industrial electronic environments. Operating temperature range spans from -40 °C minimum to 85 °C maximum, ensuring stable performance in harsh conditions.

This converter offers additional functionality such as a built-in remote ON/OFF control and overcurrent protection circuits that automatically recover, providing system reliability. It features low ripple and noise output measured at 150 mV peak-to-peak, suitable for sensitive electronics. Notably, the design excludes aluminium and tantalum electrolytic capacitors, increasing long-term reliability and lifespan.

Certified under several standards including CE, cULus, TUV, and UL 60950-1, this device meets stringent safety and quality requirements. Typically used in electronic components, power supplies, and transformers, it supports various industrial, laboratory, and commercial applications requiring stable and isolated DC power conversion.

High efficiency of 87% reduces power loss during operation. Built-in remote ON/OFF function for enhanced control. Provides I/O isolation voltage of 1.5kV AC for safety. Compact size with 25.4mm length, 9.9mm width, and depth.

Designed for industrial and electronic applications requiring stable DC power. Operates reliably within temperature range of -40°C to 85°C. Ripple and noise characteristics are low at 150mV peak-to-peak. High reliability with no built-in aluminium or tantalum electrolytic capacitors.

Complies with multiple international safety standards including CE, cUL, and TUV. Lightweight design at 20 grams suitable for PCB mounting.

Ideal for use in electrical component manufacturing, electronic circuit design, and industrial control systems, the Cosel MGS151205-R offers robust performance and durability. Explore more DC/DC Converters in the Electronics & Electricals category at EnvMart.
