Samtec SSW Series Straight Through Hole PCB Socket 3-Contact 1 Row 2.54 mm Pitch Solder SSW-103-01-L-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 655V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.7A |
| Model | SSW-103-01-L-S |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | SSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- This PCB socket features a liquid crystal polymer housing for durability and stability.
- It supports a current rating of 4.7 A per contact.
- Contact plating is gold for reliable conductivity and corrosion resistance.
- The socket has a solder termination type compatible with through hole mounting techniques.
- Operating temperature ranges from -55°C to 125°C, suitable for industrial environments.
- The connector system is board-to-board with female contact gender orientation.
- It is rated for voltage up to 655 V, making it suitable for various electronic applications.
- The SSW series includes standard and low insertion force contacts with phosphor bronze contacts.
Product Description
Samtec SSW-103-01-L-S is a high-quality Straight Through Hole PCB Socket featuring 3 contacts arranged in a single row with a 2.54 mm pitch, engineered for reliable board-to-board connections in electronic assemblies.
Constructed with a durable liquid crystal polymer housing, this socket ensures excellent mechanical strength and stability in varied operating environments. The socket's female contacts are made from phosphor bronze and plated with gold to provide excellent conductivity and corrosion resistance, supporting a continuous current rating of 4.7 Amperes per contact.
Designed for through hole mounting, the socket uses solder termination for secure installation on printed circuit boards. It is rated for a maximum voltage of 655 V, suitable for a wide range of electronic and industrial applications requiring reliable electrical connections.
The operating temperature range from -55°C to 125°C accommodates demanding environmental conditions typical in industrial, laboratory, manufacturing, and electronic equipment sectors.
The SSW series incorporates standard and low insertion force contact designs for ease of assembly without compromising electrical performance. This socket is ideal for applications in electronics manufacturing, prototyping, and repair work where durability and performance are critical.
This PCB socket features a liquid crystal polymer housing for durability and stability. It supports a current rating of 4.7 A per contact. Contact plating is gold for reliable conductivity and corrosion resistance. The socket has a solder termination type compatible with through hole mounting techniques.
Operating temperature ranges from -55°C to 125°C, suitable for industrial environments. The connector system is board-to-board with female contact gender orientation. It is rated for voltage up to 655 V, making it suitable for various electronic applications.
The SSW series includes standard and low insertion force contacts with phosphor bronze contacts. Explore Samtec SSW series and other premium PCB Sockets at EnvMart for your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 4.7 Amperes per contact.
It is rated for a maximum voltage of 655 Volts, making it suitable for various electronic applications.
The housing is made from liquid crystal polymer, while the contacts are made from phosphor bronze and plated with gold for conductivity and corrosion resistance.
The socket features a solder termination type, which is compatible with through hole mounting techniques.
It operates within a temperature range of -55°C to 125°C, suitable for demanding industrial environments.
This model features 3 contacts arranged in a single row.
The contact pitch is 2.54 mm, which is standard for many electronic applications.
The contacts in this socket are female, designed for board-to-board connections.
This PCB socket is manufactured in India.
The connector system is board-to-board, allowing for reliable connections between two printed circuit boards.
It belongs to the Samtec SSW series, which includes standard and low insertion force contacts.
The orientation of this socket is straight, designed for easy alignment during installation.
