STMicroelectronics MOSFET Gate Driver 2 Outputs 650 mA 14-Pin 17-18V SOIC L6386AD
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.65mm |
| Length | 8.75mm |
| Model | L6386AD |
| Width | 4mm |
| Mount Type | Surface |
| Series | L6386AD |
| Output Current | 650mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -45°C |
| Number of outputs | 2 |
| Rise Time | 50ns |
| Pin Count | 14 |
| Maximum Supply Voltage | 18V |
| Minimum Supply Voltage | 17V |
| Number of Drivers | 2 |
| Fall Time | 30ns |
| Driver Type | MOSFET |
Key Features
- This gate driver is designed for MOSFET applications requiring high current driving capability.
- It features dual outputs and operates efficiently at temperatures from -45°C to 125°C.
- The package is SOIC type, with dimensions 8.75mm length, 4mm width, and 1.65mm height.
- The component includes fast switching times with a rise time of 50 ns and a fall time of 30 ns.
- The device mounts on surface mount technology compatible boards.
- It supports a minimum supply voltage of 17V and maximum supply voltage of 18V.
- No automotive certifications are included with this model.
Product Description
STMicroelectronics L6386AD is a high-performance MOSFET Gate Driver designed for driving power MOSFETs in various electronic applications. With two outputs each capable of delivering 650 mA, this device ensures efficient switching for power management circuits.
The driver comes in a compact 14-pin Small Outline Integrated Circuit (SOIC) package, measuring 8.75 mm in length, 4 mm in width, and 1.65 mm in height. It operates reliably across a wide temperature range from -45°C to 125°C, making it suitable for industrial and commercial environments.
The driver features fast rise and fall times of 50 ns and 30 ns respectively, enabling rapid switching to improve circuit performance and reduce power loss. It requires a supply voltage between 17V and 18V to function within specified parameters, making it ideal for systems operating in this voltage range.
This surface mount device is free of automotive standards certification but is designed to comply with general power management needs in semiconductor applications.
Ideal use cases include industrial power management, electronics manufacturing, and embedded system designs requiring robust MOSFET gate driving capabilities. This component is packaged in tubes, suitable for automated machine insertion to enhance production efficiency.
This gate driver is designed for MOSFET applications requiring high current driving capability. It features dual outputs and operates efficiently at temperatures from -45°C to 125°C. The package is SOIC type, with dimensions 8.75mm length, 4mm width, and 1.65mm height.
The component includes fast switching times with a rise time of 50 ns and a fall time of 30 ns. The device mounts on surface mount technology compatible boards. It supports a minimum supply voltage of 17V and maximum supply voltage of 18V.
No automotive certifications are included with this model. Browse our Electronics & Electricals and Power Management ICs categories for more STMicroelectronics components and gate drivers.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model can deliver an output current of 650 mA from each of its two outputs, making it suitable for high current driving applications.
It operates efficiently across a wide temperature range from -45°C to 125°C, suitable for various industrial and commercial environments.
The package measures 8.75 mm in length, 4 mm in width, and 1.65 mm in height, making it compact for surface mount applications.
The driver features a rise time of 50 ns and a fall time of 30 ns, enabling rapid switching to enhance circuit performance.
It requires a minimum supply voltage of 17V and a maximum supply voltage of 18V to function within its specified parameters.
This gate driver has two outputs, allowing it to drive multiple MOSFETs simultaneously.
Yes, it is designed for surface mount technology and can be mounted on compatible boards for automated machine insertion.
It is intended for use in industrial power management, electronics manufacturing, and embedded system designs requiring robust MOSFET gate driving capabilities.
This model has a pin count of 14, which is standard for its SOIC package type.
No, this model does not include any automotive certifications.
The L6386AD is part of the L6386AD series of MOSFET gate drivers from STMicroelectronics.
The country of origin for this MOSFET gate driver is India.
