TDK Standard Metal Oxide Varistor Radial 1.85nF Capacitance 100A Clamping Current 2970V Clamping Voltage B72220S0131K101

Free Delivery in India | Lowest Global Shipping Charges

TDK Standard Metal Oxide Varistor Radial 1.85nF Capacitance 100A Clamping Current 2970V Clamping Voltage B72220S0131K101



Category Varistor Brand TDK Condition New

Specifications

Country of Origin	India
Diameter	21.5mm
Brand	TDK
Material	Metal
THICKNESS	4.7mm
Length	50.5mm
Model	B72220S0131K101
Depth	4.7mm
Mount Type	Lead
Series	Standard
Energy Rating	1J
Maximum Operating Temperature	85°C
Capacitance	1.85nF
Minimum Operating Temperature	-40°C
Maximum dc Voltage	1465V dc
Standards/Approvals	IEC, CQC, UL, CSA, VDE
Package/Case	Radial
Pin Count	2
Lead Pitch	10mm
Maximum AC Voltage	1100V ac
Clamping Voltage VC	2970V
Clamping Current	100A
Maximum Surge Current	8kA
Varistor Voltage	205 V

Key Features

Standard series radial epoxy-coated metal oxide varistor.
Tinned copper wire leads with ceramic epoxy resin body for durability.
Rated for 8/20 μs surge current and 2ms energy rating of 1J.
Clamping voltage of 2970V and varistor voltage of 205V.
Operating temperature from -40°C to 85°C.
Lead pitch of 10mm with 2 pins.
Compliance with IEC, CQC, UL, CSA, and VDE standards.
Maximum AC voltage 1100V and DC voltage 1465V.

Product Description

TDK B72220S0131K101 Standard Metal Oxide Varistor is a radial epoxy-coated MOV designed for high reliability surge protection in electronic and industrial systems. It features a capacitance of 1.85nF and a clamping current rating of 100A, safeguarding circuits from overvoltage conditions effectively.

The varistor has a clamping voltage of 2970V and a rated varistor voltage of 205V. Its radial package includes tinned copper wire leads and a ceramic body coated with epoxy resin to ensure mechanical robustness and electrical insulation.

Operating within a temperature range of -40°C to 85°C, this varistor suits various environmental conditions. Dimensions include a 21.5mm diameter, 50.5mm length, and 4.7mm thickness, with a 10mm lead pitch for easy PCB mounting and integration.

Compliance with international standards such as IEC, CQC, UL, CSA, and VDE guarantees quality and safety, making it ideal for industrial surge protection, power supplies, and electronic equipment.

Standard series radial epoxy-coated metal oxide varistor. Tinned copper wire leads with ceramic epoxy resin body for durability. Rated for 8/20 μs surge current and 2ms energy rating of 1J. Clamping voltage of 2970V and varistor voltage of 205V.

Operating temperature from -40°C to 85°C. Dimensions: 21.5mm diameter, 50.5mm length, 4.7mm thickness. Lead pitch of 10mm with 2 pins. Compliance with IEC, CQC, UL, CSA, and VDE. Maximum AC voltage 1100V and DC voltage 1465V.

This Varistor is primarily used in industrial, electronic components manufacturing, power supplies, and surge protection circuits to enhance equipment durability and safety. Discover a wide range of high-quality electrical components and surge protection devices in EnvMart's Electronics Components category for your industrial and manufacturing needs.
