TDK Standard Metal Oxide Varistor 2.9 nF Capacitance 100 A Clamping Voltage 2970 V Lead Mount Radial B72220S0750K101

TDK B72220S0750K101 Standard Metal Oxide Varistor offers an effective solution for surge protection in electronic components and power systems. It features a metal oxide varistor design with a capacitance of 2.9 nF and a clamping voltage of 2970 V, making it suitable for absorbing and dissipating transient voltage spikes to safeguard sensitive devices.

This radial termination varistor uses lead mount style, facilitating straightforward implementation in various circuits. The ceramic body coated with epoxy resin and tinned copper leads ensure durability and reliable performance under demanding industrial conditions. Operating temperature ranges from -40°C to 85°C, supporting versatile usage environments.

The device complies with international safety standards including IEC, UL, CSA, VDE, and CQC, endorsing its quality and suitability for industrial, commercial, and laboratory applications. Its physical dimensions - 21.5 mm diameter, 50.5 mm length, and 4.6 mm thickness - cater to compact circuit designs without compromising on surge handling capacity.

Applications range across electronic circuit boards, power distribution units, control panels, and surge protection in industrial machinery. It can effectively manage surge currents up to 100 A and withstand maximum surge currents of 6.5 kA, providing robust overload defense.

Capacitance of 2.9 nF ensures stable electrical performance. Lead mount type with radial termination for easy installation. Maximum operating temperature of 85°C suitable for varied environments. Constructed with metal and epoxy-coated ceramic body for durability.

Complies with IEC, UL, CSA, VDE, and CQC standards for safety and reliability. Diameter measures 21.5 mm with length of 50.5 mm and thickness of 4.6 mm. Rated for maximum AC voltage of 1100 V AC and maximum surge current of 6.5 kA.

Pin count of 2 with 10 mm lead pitch for compatibility with standard circuit boards. Operating temperature range from -40°C to 85°C suitable for industrial applications. Standard series metal oxide varistor ideal for surge protection in power and electronics systems.

This metal oxide Varistor is an essential component to protect electronics from transient voltage surges in diverse environments such as industrial power supplies, manufacturing equipment, HVAC controllers, and laboratory testing setups. Its reliable construction and certification assure long-lasting operation and safety compliance.
