HARWIN M80 Series Straight Through Hole PCB Socket 14-Contact 2 Row 2 mm Pitch Solder M80-8501445

HARWIN M80-8501445 Straight Through Hole PCB Socket is a premium-grade electronic component designed for reliable board-to-board connection in industrial, manufacturing, and commercial electronics applications. It features 14 female contacts arrayed in 2 rows with a 2 mm pitch, ensuring precise alignment and efficient use of PCB space.

The socket’s housing is made of robust nylon material that provides excellent mechanical strength and electrical insulation. Contacts are crafted from brass and beryllium copper alloy, plated with gold to offer superior conductivity, durability, and corrosion resistance. This combination ensures the connector maintains integrity even under demanding conditions such as high vibration, shock, and temperature extremes.

This connector supports through-hole mount technology with a straight orientation, facilitating reliable soldering and mechanical stability on printed circuit boards. It is rated for 12A current at 120V, making it suitable for medium power electronic circuits.

Operating temperature ranges from -55°C to 125°C, enabling use in harsh and industrial environments without performance degradation. The polarised moulding design guarantees proper mating with corresponding connectors, preventing incorrect or incomplete connections.

The M80 series is recognized for its high reliability four-finger beryllium copper contacts that offer increased contact robustness and multiple mating cycles without performance loss. This makes it excellent for applications requiring long-lasting and secure electrical connections.

Compliant with qualitative standards such as BS9525-F0033, MIL C 55302, and CEC 75101-008, this PCB socket integrates seamlessly with industry-standard connectors and is highly suited for commercial off-the-shelf (COTS) products.

This product is made in the United Kingdom and is ideal for electronic design engineers, PCB assemblers, and industrial manufacturing facilities focusing on durable and performance-critical electrical connections.

Features 14 female contacts arranged in 2 rows for compact connectivity. Constructed with nylon housing providing durability and insulation. Gold plated brass and beryllium copper alloy contacts offer excellent conductivity and corrosion resistance.

Rated for a current of 12A and a voltage of 120V for moderate power applications. Supports through-hole mounting with a straight orientation for secure board connections. Operates effectively within a temperature range of -55°C to 125°C, suitable for harsh environments.

Polarised mouldings ensure correct mating and prevent misconnection. Complies with high reliability standards, designed for vibration, shock, and acceleration resistance. Ideal for industrial, electronics manufacturing, and rugged product applications requiring durable PCB connections.
