Nexperia General Purpose NPN Transistor 1 A 80 V 4-Pin SOT-223 BCP56-10,115
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.65mm |
| Length | 6.7mm |
| Model | BCP56-10,115 |
| Width | 7.3mm |
| Mount Type | Surface |
| Series | BCP56 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-223 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 4 |
| Maximum Collector Emitter Voltage Vceo | 80V |
| Minimum DC Current Gain hFE | 40 |
| Transistor Polarity | NPN |
| Maximum Emitter Base Voltage VEBO | 5V |
| Maximum Collector Base Voltage VCBO | 100V |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 960mW |
| Maximum DC Collector Current Idc | 1A |
| Transistor Configuration | Single |
| Maximum Transition Frequency ft | 180MHz |
| onsemi BCP56-10T1G Transistor, 1 A NPN, 80 V, 4-Pin SOT-223Brand | onsemi |
| Nexperia BCP56-16,115 Transistor, 1 A NPN, 80 V, 4-Pin SOT-223Brand | Nexperia |
Key Features
- Maximum collector current of 1 ampere for reliable switching.
- Collector-emitter voltage rating up to 80 volts ensuring robustness.
- Surface-mounted SOT-223 package with 4 pins for easy PCB integration.
- High maximum power dissipation of 960 milliwatts for efficient operation.
- Wide operating temperature range from -55 to 150 degrees Celsius.
- High frequency operation with transition frequency up to 180 MHz.
- Automotive grade AEC-Q101 standard compliant for automotive applications.
- NPN polarity suitable for typical amplification and switching circuits.
Product Description
Nexperia BCP56-10,115 is a general-purpose NPN bipolar transistor optimized for switching and amplification applications in electronic circuits. This transistor supports a maximum DC collector current of 1 ampere and a maximum collector-emitter voltage of 80 volts, making it suitable for medium power applications.
It comes in a compact 4-pin SOT-223 surface-mount package that facilitates easy mounting on PCBs with reliable mechanical and electrical connections.
The device has a maximum power dissipation of 960 milliwatts and operates over a wide temperature range from -55°C to 150°C, allowing it to perform reliably under harsh industrial and automotive conditions.
Its transition frequency of 180 MHz allows high-speed switching, ideal for audio, telecommunications, and general electronics applications. Supports maximum collector current of 1 A. Collector-emitter voltage rating of 80 V for robustness.
Surface-mount SOT-223 package with 4 pins. Maximum power dissipation of 960 mW. Wide operating temperature range (-55°C to 150°C). Transition frequency of 180 MHz for high-speed operation. Meets AEC-Q101 automotive quality standards.
Small size dimensions for compact circuit design. Minimum DC current gain of 40 for effective amplification. NPN transistor polarity for general switching and amplification use. This transistor is widely utilized in automotive electronics, industrial automation, consumer electronics, telecommunications, and power management circuits.
It is compliant with RoHS standards ensuring environmental safety.
Explore the Electronics & Electricals Semiconductors category at EnvMart for compatible Bipolar Transistors and electronic components suitable for various industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum collector current of this transistor is 1 ampere, making it suitable for medium power applications.
The collector-emitter voltage rating for the BCP56-10,115 is up to 80 volts, ensuring robustness in various applications.
It comes in a surface-mounted SOT-223 package with 4 pins, facilitating easy integration onto PCBs.
The maximum power dissipation for this transistor is 960 milliwatts, allowing for efficient operation.
The operating temperature range is from -55°C to 150°C, making it suitable for harsh environments.
The transition frequency of the BCP56-10,115 is up to 180 MHz, allowing for high-speed switching applications.
The minimum DC current gain (hFE) for this transistor is 40, which is effective for amplification purposes.
Yes, it meets the AEC-Q101 automotive quality standards, making it suitable for automotive applications.
The dimensions are 6.7 mm in length, 7.3 mm in width, and 1.65 mm in height.
This model has an NPN polarity, which is typical for amplification and switching circuits.
The maximum emitter-base voltage (VEBO) for the BCP56-10,115 is 5 volts.
Yes, this transistor is compliant with RoHS standards, ensuring environmental safety.
