Nexperia 1.3 W 6.8 V Voltage Regulator Zener Diode, Single, Through Hole, 2-Pin DO-41 BZV85-C6V8,113

Nexperia BZV85-C6V8,113 is a high-quality 1.3 watt zener diode with a nominal zener voltage of 6.8 V. It is designed for voltage regulation applications in electronic and industrial circuits requiring stable voltage referencing. The device utilizes a through hole mount style with a 2-pin DO-41 package, simplifying PCB assembly with its single diode configuration.

This zener diode features a maximum power dissipation rating of 1.3 W and a zener voltage tolerance of ±5%, making it suitable for precision voltage regulation and protection tasks. It operates stably over a wide temperature range from -65°C to 200°C, making it ideal for demanding environments.

The device has a maximum reverse leakage current of 2 μA and a typical zener impedance of 3.5 Ω, which ensures low noise and improved performance in sensitive electronic applications. With a test current of 35 mA and a voltage temperature coefficient of 2.8 mV/°C, it maintains consistent voltage performance across varying operating conditions.

The diode is commonly used in industrial electronics, power supplies, laboratory equipment, and consumer electronic devices for voltage regulation and voltage clamp functionalities.

Its compact DO-41 through hole package, measuring 4.8 mm in length and 2.6 mm in height, provides easy mounting and efficient thermal dissipation. This makes it a versatile zener diode suitable for industrial, laboratory, and electronics manufacturing applications.

This diode features a nominal zener voltage of 6.8 V with ±5% tolerance. It has a maximum power dissipation of 1.3 watts suitable for low power applications. The package type is DO-41 with 2 pins for through hole mounting.

Typical test current is 35 mA with a maximum zener impedance of 3.5 ohms. It operates reliably from -65°C up to 200°C ambient temperature. Maximum reverse leakage current is 2 microamperes ensuring minimal leakage. Its voltage temperature coefficient is 2.8 mV/°C maintaining stable voltage across temperature variations.

This diode is ideal for voltage regulation in electronic circuits needing precise voltage clamps. Explore more semiconductor components like this in the Electronics & Electricals category at EnvMart.
