Samtec Pin Header 3 Contact 2.54 mm Pitch 1 Row Unshrouded Through Hole Board-to-Board Connector TSW-103-23-S-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-103-23-S-S |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Operating temp range | -55 °C to +125 °C with Gold -55 °C to +105 °C with Tin |
| Plating used | Au or Sn over 50 μ" (1.27 μm) Ni |
Key Features
- The housing is made from durable glass filled polyester material.
- Contacts are male, made of phosphor bronze with gold plating for reliable connectivity.
- The connector system is board-to-board with a straight orientation.
- Operating temperature ranges from -55°C to 125°C with gold plating for extended durability.
- The rated voltage is up to 550 V suitable for various electronic applications.
- The termination type is solder for secure PCB mounting.
- This pin header is RoHS compliant, ensuring environmentally safe usage.
- The plating used is gold or tin over 50 μ" (1.27 μm) nickel base for corrosion resistance.
Product Description
Samtec TSW-103-23-S-S is a precision pin header featuring 3 contacts arranged in a single row with a 2.54 mm pitch. It is designed for through hole mounting and offers a straight orientation ensuring stable and reliable board-to-board electrical connections.
The housing is constructed from black glass filled polyester which provides excellent mechanical strength and thermal stability. The contacts are made from phosphor bronze with gold plating, enhancing conductivity and resisting corrosion, enabling operation in temperatures ranging from -55 °C to 125 °C when gold plated.
This pin header supports a voltage rating up to 550 V, making it suitable for various demanding electronic applications including industrial automation, control systems, instrumentation, and consumer electronics. Its solder termination ensures firm attachment to printed circuit boards.
The unshrouded, straight through hole design enhances ease of access and assembly in electronic manufacturing processes. The plating system comprises gold or tin over a 50 μ" nickel base, offering high reliability and durability in diverse environmental conditions.
Samtec TSW series conform with RoHS environmental standards, ensuring compliance with regulations on hazardous substances. The housing material is glass filled polyester for durability. Contact material is high-quality phosphor bronze with gold plating.
Operating temperature range supports broad environmental conditions. Rated voltage is up to 550 V for versatility. Unshrouded design simplifies installation. Suitable for industrial, electronic component manufacturing, and prototyping use cases.
Explore more PCB connectors and headers from Samtec in EnvMart’s electronics components collection to meet your precise application needs.
Explore more products in our PCB Pin Header category.
