Samtec Pin Header 3 Contacts 2.54 mm Pitch 1 Row Unshrouded Board-to-Board Through Hole TSW-103-14-L-S

Samtec TSW-103-14-L-S is a high-quality pin header designed for board-to-board connection with a 2.54 mm pitch and 3 contacts arranged in a single row. This unshrouded connector is manufactured with a Polybutylene Terephthalate housing to provide excellent mechanical stability and electrical insulation.

The connector employs male phosphor bronze contacts plated with gold, ensuring optimal electrical conductivity and resistance to corrosion. Rated for 4.3 amperes current and 550 volts, it is suitable for various electronic components and power distribution applications. The operating temperature range from -55°C to 125°C ensures dependable function under harsh environmental conditions.

This through-hole type connector features straight orientation with a tail pin length of 2.79 mm and mating pin length of 8.13 mm to facilitate secure soldering and reliable mating with other connectors. The unshrouded design allows easy visual inspection and maintenance, making it ideal for electronic assembly, manufacturing, and repair tasks.

Its specialized square post contact system enhances contact reliability, and the design offers many options for optimizing cost and performance, including plating and ruggedizing features.

Ideal for industrial electronics, telecommunications, computing hardware, and laboratory equipment, this pin header supports robust and consistent electrical connections. The versatile connector is commonly used in PCB headers and wire housings for effective signal and power transmission.

Designed with a pitch of 2.54 mm for standard PCB compatibility. Features 3 male phosphor bronze contacts plated with gold for corrosion resistance. Offers a current rating of 4.3 amperes and voltage rating of 550 volts.

Made using durable Polybutylene Terephthalate housing material. Operating temperature range from -55°C to 125°C ensures reliability in varied conditions. Unshrouded design allows easy access for solder termination. Tail pin length is 2.79 mm and mating pin length is 8.13 mm for secure connection.

Connector orientation is straight with through-hole mounting type. Suitable for a wide range of electronic and power connector applications. Explore more quality PCB connectors like the Samtec TSW series in the Electronics Components category at EnvMart.
