Samtec Pin Header 3 Contacts 2.54 mm Pitch 1 Row Unshrouded Through Hole TSW-103-14-T-S-LL
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-103-14-T-S-LL |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Operating temp range | -55 °C to +125 °C with Gold -55 °C to +105 °C with Tin |
| Plating used | Au or Sn over 50 μ" (1.27 μm) Ni |
Key Features
- Constructed with black glass filled polyester housing material for durability.
- Phosphor bronze contacts plated with gold ensure reliable electrical connection.
- Designed for a wide operating temperature range from -55°C to 125°C with gold plating.
- Supports a voltage rating of up to 550V for robust performance.
- Suitable for board-to-board connector system with straight orientation and male contacts.
- Termination is by solder, enhancing secure and stable assembly.
- Unshrouded design allows easy access and visibility of contacts.
Product Description
Samtec TSW-103-14-T-S-LL is a high-quality through-hole pin header designed for electronics and electrical industrial applications. Featuring 3 contacts arranged in a single row with 2.54 mm pitch and unshrouded housing, this component offers robust performance and reliable connectivity.
The housing is made from black glass filled polyester, providing excellent insulation and mechanical strength. The contacts are manufactured from phosphor bronze, a material known for strength and conductivity, and plated with gold over nickel plating to ensure corrosion resistance and low contact resistance. The operating temperature range is from -55°C to 125°C when using gold plating, making it suitable for demanding environments.
This pin header supports a voltage rating of up to 550V, making it suitable for board-to-board applications requiring high insulation and safety standards. Its straight orientation and male contact gender facilitate easy integration during assembly with solder termination ensuring secure mechanical and electrical connection.
Black glass filled polyester housing offers electrical insulation and durability. Phosphor bronze contacts with gold plating provide long-term reliable conductivity. Wide temperature operating range of -55°C to 125°C ensures performance stability.
Rated voltage up to 550V supports high voltage applications. Unshrouded design supports easy soldering and inspection. Suitable for board-to-board connector systems in electronics manufacturing. Termination by solder for secure and permanent connections.
This pin header is widely used in industrial electronics, manufacturing, and laboratory equipment for electrical interconnections, ensuring reliable signal and power transfer. Its compliant design with RoHS standards supports environmentally friendly manufacturing practices.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a voltage rating of up to 550V, making it suitable for high voltage applications.
The pin header operates within a temperature range of -55°C to 125°C when using gold plating, ensuring performance stability in demanding environments.
The contacts are made from phosphor bronze and are plated with gold over nickel for corrosion resistance and low contact resistance.
This pin header features 3 contacts arranged in a single row with a 2.54 mm pitch.
Termination is by solder, which enhances secure and stable assembly during installation.
The housing is constructed from black glass filled polyester, providing excellent insulation and mechanical strength.
Yes, it is designed for board-to-board connector systems, facilitating easy integration during assembly.
This model has a straight orientation, which aids in straightforward installation.
The unshrouded design allows for easy access and visibility of contacts, simplifying the soldering process and inspection.
The country of origin for this pin header is India.
This model is compliant with RoHS standards, supporting environmentally friendly manufacturing practices.
The contact gender of this unit is male, which is standard for many electronic connections.
