Nexperia Surface Mount Schottky Diode 30 V 200 mA 2-Pin I-IGIA Package 1PS79SB31,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Surface Mount Schottky Diode 30 V 200 mA 2-Pin I-IGIA Package 1PS79SB31,115

Name: Nexperia Surface Mount Schottky Diode 30 V 200 mA 2-Pin I-IGIA Package 1PS79SB31,115
Brand: Nexperia
SKU: 162529
Price: 20.22 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	0.65mm
Length	1.25mm
Model	1PS79SB31,115
Width	0.85mm
Mount Type	Surface
Series	1PS79SB31
Maximum Operating Temperature	125°C
Package Type	I-IGIA
Minimum Operating Temperature	-65°C
Pin Count	2
Maximum Continuous Forward Current If	200mA
Peak Reverse Repetitive Voltage Vrrm	30V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	30μA
Peak Non-Repetitive Forward Surge Current Ifsm	1A
Maximum Forward Voltage Vf	500mV
onsemi 30 V 200 mA Diode Schottky 2-Pin SOD-523Brand	onsemi

Key Features

Rated for a maximum continuous forward current of 200 mA.
Maximum reverse repetitive voltage of 30 V supports moderate voltage circuits.
Ultra-small 2-pin I-IGIA package enables compact board designs.
Features a low forward voltage drop of 500 mV for high efficiency.
Operating temperature range from -65°C to 125°C ensures reliability in diverse environments.
Low leakage current of 30 μA minimizes power losses in standby modes.
Capable of withstanding a peak non-repetitive forward surge current of 1 A.
Optimized for low capacitance and negligible power switching losses.

Product Description

Nexperia 1PS79SB31,115 is a high-efficiency Schottky barrier diode packaged in an ultra-small I-IGIA surface-mount form factor. It is rated for 30 V reverse voltage and 200 mA continuous forward current, making it suitable for low voltage, low current rectification tasks in electronic circuits.

The diode features a low forward voltage drop of 500 mV, which contributes to reduced power dissipation and higher overall system efficiency. Its low leakage current of 30 μA and low capacitance make it ideal for switching applications with minimal energy loss.

Operating temperature range from -65°C to 125°C ensures robust performance in industrial, automotive, telecommunications, and power supply applications where thermal stability is critical.

This 2-pin Schottky diode withstands peak non-repetitive surge currents up to 1 A, providing protection during transient conditions. Its compact height of 0.65 mm, length of 1.25 mm, and width of 0.85 mm support dense PCB layouts in compact electronic devices.

Though not certified for automotive use, it finds broad applications in industrial and commercial electronics, including power rectification, voltage clamping, and reverse current protection in power supplies, LED drivers, and signal processing circuits.

Rated maximum forward current of 200 mA. Peak reverse voltage rating of 30 V. Low forward voltage of 500 mV for efficiency. Wide operating temperature from -65°C to 125°C. Compact I-IGIA surface mount package with 2 pins.

Low leakage current of 30 μA minimizes power loss. Peak surge forward current of 1 A withstands transients. Perfect for industrial, laboratory, and telecommunications applications. Manufactured in China. Explore more Schottky diodes and rectifiers on EnvMart for your electronic component needs.
