Nexperia Low Saturation Voltage PNP Bipolar Transistor 1 A 100 V 4-Pin UPAK PBSS9110X,135

Nexperia PBSS9110X,135 is a low saturation voltage PNP bipolar junction transistor designed for high collector current capacity of 1 A and collector-emitter voltage up to 100 V housed in a compact 4-pin UPAK surface mount package.

This transistor's reduced saturation voltage leads to lower power loss and heat generation, making it highly efficient in switching and digital electronics applications including automotive and industrial circuits.

It supports a maximum power dissipation of 2 W and a DC current gain hFE minimum of 125, ensuring reliable amplification and switching performance. The device is designed to operate reliably within temperature extremes from -65°C up to 150°C with a maximum transition frequency of 100 MHz for fast switching needs.

The package dimensions are 4.5 mm length, 2.5 mm width, and 1.5 mm height, suitable for surface mounting to save PCB space. It complies with automotive standard AEC-Q101, making it appropriate for demanding automotive applications.

Maximum collector current of -1 A. Collector-emitter voltage rating of -100 V. Low saturation voltage design reduces losses and heat. Compact 4-pin UPAK surface mount package. High current gain to support amplification. Wide operating temperature range from -65°C to 150°C.

Transition frequency up to 100 MHz for high-speed operation. AEC-Q101 automotive standard compliant. Dimensions: 4.5 mm length, 2.5 mm width, 1.5 mm height.

This transistor is ideal for use across industrial, automotive, and electronic manufacturing sectors where efficiency, reliability, and compact form factors are critical. Explore more high-quality Bipolar Transistors and semiconductor components at EnvMart.
